4.852K 3950k NTC Temperature Sensor For AC Vehicle And Evaporator
4.852K 3950k NTC Temperature Sensor For AC Vehicle And Evaporator
4.852K 3950k NTC Temperature Sensor For AC Vehicle And Evaporator
4.852K 3950k NTC Temperature Sensor For AC Vehicle And Evaporator
4.852K 3950k NTC Temperature Sensor For AC Vehicle And Evaporator
4.852K 3950k NTC Temperature Sensor For AC Vehicle And Evaporator
4.852K 3950k NTC Temperature Sensor For AC Vehicle And Evaporator
4.852K 3950k NTC Temperature Sensor For AC Vehicle And Evaporator
Specifications
Brand Name :
JP SENSOR
Model Number :
MFP
Certification :
ISO9001, RoHS
Place of Origin :
Anhui, China
MOQ :
1000 Pieces
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
200 Million per Year
Delivery Time :
2 Weeks
Packaging Details :
Carton Packing
Resistance :
R0℃=4.852KΩ
B Value :
B25/50=3950K
Operating temperature range :
-40℃~105℃
Application :
AC in vehicles and evaporator
Chip :
NTC Thermistor
Probe :
Aluminum probe
Encapsulation :
Epoxy resin
Cable :
PVC 24AGW 105 ℃
Description

4.852K 3950k NTC Temperature Sensor For AC Vehicle And Evaporator

Brief Instruction (Product Description):

This product is mainly used for the temperature measurement of AC in vehicles and evaporators, of which the resistance is generally R0℃=4.852KΩ, B25/50=3950K (Can be customized), its probe is an aluminum shell. It can add a cable extension connector if the customer requires it.

Features:

Comply with RoHS standard

Operating temperature range: -40℃~105℃

Easy to install

Stable

Fast Response

Application:

AC in vehicles and evaporator

Structure and Dimensions:(unit: mm)

4.852K 3950k NTC Temperature Sensor For AC Vehicle And Evaporator

Electrical Specification:

Rec. at 25℃(kΩ) Beta value (In air) Pmax(mW) δ(mW/℃) Thermal time constant τ(sec.) Operating Temperature Range TL-TH(℃) Total length
L(mm)
1 B25/85=3435 Approx.60 Max.3.0 Max.20 -40℃~125℃ 8~100
1.5 B25/50=3850
1.5 B25/50=3935
2 B25/85=3550
2 B25/85=3935
2.08 B25/85=3580
2.2 B25/50=3935
3 B25/50=3950
5 B25/50=3470
5 B25/50=3950
8 B25/100=3988
10 B25/85=3435
10 B25/50=3470
10 B25/50=3935
10 B25/50=3950
20 B25/50=3950
47 B25/50=3950
50 B25/50=3950
50 B25/50=4200
100 B25/50=4200
200 B25/50=4200
500 B25/50=4450
1000 B25/85=4600
