10Kohm 3435K NTC Chip Thermistor Small Dimension Silver Electrode High Soldering Resistance
10Kohm 3435K NTC Chip Thermistor Small Dimension Silver Electrode High Soldering Resistance
10Kohm 3435K NTC Chip Thermistor Small Dimension Silver Electrode High Soldering Resistance
10Kohm 3435K NTC Chip Thermistor Small Dimension Silver Electrode High Soldering Resistance
10Kohm 3435K NTC Chip Thermistor Small Dimension Silver Electrode High Soldering Resistance
10Kohm 3435K NTC Chip Thermistor Small Dimension Silver Electrode High Soldering Resistance
10Kohm 3435K NTC Chip Thermistor Small Dimension Silver Electrode High Soldering Resistance
10Kohm 3435K NTC Chip Thermistor Small Dimension Silver Electrode High Soldering Resistance
10Kohm 3435K NTC Chip Thermistor Small Dimension Silver Electrode High Soldering Resistance
10Kohm 3435K NTC Chip Thermistor Small Dimension Silver Electrode High Soldering Resistance
10Kohm 3435K NTC Chip Thermistor Small Dimension Silver Electrode High Soldering Resistance
10Kohm 3435K NTC Chip Thermistor Small Dimension Silver Electrode High Soldering Resistance
Specifications
Brand Name :
JP SENSOR
Model Number :
Chip Termistor
Certification :
ISO9001, RoHS
Place of Origin :
Anhui, China
MOQ :
1000 Pieces
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
200 Million per Year
Delivery Time :
2 Weeks
Packaging Details :
Carton Packing
Resistance :
10KΩ
B Value :
3435K
Resistance Tolerance :
1%, ±2%, ±3%, ±5%
Features :
Comply with RoHS standard Silver electrode Small dimension Stable High Soldering Resistance
Application :
It is used to fabricate NTC Thermistor and temperature sensor.
Customization :
Available
Description

10Kohm 3435K NTC Chip Thermistor Small Dimension Silver Electrode High Soldering Resistance

Product Description:

10KΩ 3435k NTC Thermal chip is widely used in many industries, which is mainly used in power tools, batteries, new energy vehicles, equipment testing, etc. The 10KΩ 3435k chip is produced by our company, which can be divided into 5 kinds according to the resistance tolerances. Tolerances are 1%, ±2%, ±3%, ±5%.

Features:

Comply with RoHS standard

Silver electrode

Small dimension

Stable

High Soldering Resistance

Application:

It is used to fabricate NTC thermistors and temperature sensors.

Part Number Code:

10Kohm 3435K NTC Chip Thermistor Small Dimension Silver Electrode High Soldering Resistance

Structure and Dimension:

10Kohm 3435K NTC Chip Thermistor Small Dimension Silver Electrode High Soldering Resistance

Electrical Specification:

Rec. at 25℃(kΩ)+A2:G25+A2:G25 Beta value

(In air)

Pmax(mW)

 δ(mW/℃) Thermal time constant τ(sec.) Operating Temperature Range TL-TH(℃) Total length
L(mm)
1 B25/85=3435 / / / / /
1.5 B25/50=3850
1.5 B25/50=3935
2 B25/85=3550
2 B25/85=3935
2.08 B25/85=3580
2.2 B25/50=3935
3 B25/50=3950
5 B25/50=3470
5 B25/50=3950
8 B25/100=3988
10 B25/85=3435
10 B25/50=3470
10 B25/50=3935
10 B25/50=3950
20 B25/50=3950
47 B25/50=3950
50 B25/50=3950
50 B25/50=4200
100 B25/50=4200
200 B25/50=4200
500 B25/50=4450
1000 B25/85=4600
