SS304​ Temperature Humidity Controlled Cabinets Antiwear Climatic Test Chamber
SS304​ Temperature Humidity Controlled Cabinets Antiwear Climatic Test Chamber
SS304​ Temperature Humidity Controlled Cabinets Antiwear Climatic Test Chamber
SS304​ Temperature Humidity Controlled Cabinets Antiwear Climatic Test Chamber
Specifications
Brand Name :
GSKA
Model Number :
Temperature Humidity Chamber
Certification :
CE SGS ROHS UL CE
Place of Origin :
Dongguan China
MOQ :
Negotiate
Price :
Negotiate
Payment Terms :
T/T, L/C
Supply Ability :
100 Set / Sets per Month
Delivery Time :
10-60days after confirmed payment or by contract stipulation
Packaging Details :
Export package
Uniformity :
±2°C;±3.0%RH
Cooling Type :
Water Cold
Temperature fluctuation :
±1.0℃
Temperature uniformity :
±2.0℃
Power :
220V , 50Hz
Condenser :
Water-cooled condensing agent
Controller resolution :
±0.3℃；±2.5%RH
keyword :
Temperature Humidity Chamber
Description

SS304​ Temperature Humidity Controlled Cabinets Antiwear Climatic Test Chamber

Product description:

This equipment can keep the temperature and humidity setup by users.Its' value can be alternative changed through the software.The device is application to test and confirm the property of heat-resisting,cold-resisting,drying-resisting,humidity-resisting.,etc.It is widely used in the field of electron,electric equipment,communication,instrument,car,plastic,metal,food,chemical,building materials,medical,spaceflight.,etc.

Control:


English LCD display LCD touch-panel, the screen on the input data, and programmable temperature and humidity, backlight adjustable 17, curve, curve of setting/display value. Can display a variety of alerts, failure occurs through the screen display, eliminating failures, eliminate misuse. Multi-PID control functions, sophisticated monitoring functions, and the data displayed on the screen.

Technical Specification:

Parameter Temp. range Model S:-70°C~+150°C ,Model L: -40°C~+150°C
Humidity Range 20% ~ 98% R.H
Humidity bias +2~-3%R.H
Temp. fluctuation ≤±0.5°C
Temp. uniformity ≤2°C
Heating rate 1.0~3.0°C/min
Cooling rate 1~1.5°C/min
Material Shell material High-quality SUS304 stainless steel plate
Liner material High-quality SUS304 stainless steel plate
Insulation materials Ultra-fine glass fiber insulation cotton / rigid polyurethane foam
Door seal Double resistance to high and low temperature aging and hardening of refined silicone seal
Cold and heat exchange system Controller JIANQIAO Special color touch screen Controller
Accuracy range: temperature ± 0.1 °C, indicating accuracy: temperature ± 0.1 °C, resolution: ± 0.1 °C
Circulatory system Temperature low-noise motors, cycles, , stainless steel multi-leaf type centrifugal fan,the test time can set 999999 hours
Water supply Electronic device controller automatic control of liquid, and more than recycled water, with water alarm
Humidification mode External isolated, stainless steel electric steam humidification mode occurs
Dehumidification mode Condensation method using the dew point temperature of the evaporator coil dehumidification mode laminar contacts
Refrigeration Unit cooling mode / Dual (cascade) cooling method (air-cooled)
Condenser/ Evaporator Tecumseh
Compressor France " Tecumseh " closed refrigeration compressor / France "Taikang" Hermetic Refrigeration Compressors
Security Devices Power overload, leakage, grounding, over-temperature protection (with voice prompts), fast fuse, compressor over-voltage protection
Standard

Resistant to high and low temperature heat tempered glass hollow glass windows:

300 × 200 (mm), a lighting, , the two sample holder,
Power supply ACø220V·50HZ/380V·50HZ
Ambient temperature 15°C~+30°C ≤85%R.H

Standard Features:

1. Stainless# 304 steel for interior

2. ​Paint steel for exterior

3. Foam-insulated door for rigidity and long life

4. Plastic water tank easy for maintenance

5. Observation Window with frost free function

6. High performance refrigeration system

7. Easy user interface for TEMI-880 PLC controller


SS304​ Temperature Humidity Controlled Cabinets Antiwear Climatic Test Chamber


We keep good quality and competitive price to ensure our customers benefit ; We respect every customer as our friend and we sincerely do business and make friends with them,no matter where they come from. Each batch of parts is done quality sampling inspection before into the warehouse, and Each product before delivery is tested by the national authoritative third-party inspection agency

Customer Support Services:

Ø Installation


Ø Training (Training customer employees)


Ø Calibration


Ø Preventative maintenance


Ø Replacement parts


Ø Assistance via phone or internet
