Horizontal Universal Material Testing Machine Microcomputer Controlled 300KN Max Test Force
Horizontal Universal Material Testing Machine Microcomputer Controlled 300KN Max Test Force
Specifications
Brand Name :
PERFECT
Model Number :
PT-LEW-300
Certification :
ISO9001
Place of Origin :
Dongguan, Guangdong,China
MOQ :
1 set
Price :
Negotiable
Payment Terms :
T/T, L/C, Western Union
Supply Ability :
20 Sets Per Month
Delivery Time :
35-45 days afer confirm order
Packaging Details :
Strong Wooden Case
Test speed :
0-120mm/min
Piston stroke :
1000mm
Displacement measurement range: :
1000mm
Test space :
500-6000mm (500mm); not including the piston stroke
Max.Test Force :
300KN
Test force resolution :
1/300000 code
Displacement measurement resolution :
0.01mm
Description

Horizontal Universal Material Testing Machine Microcomputer Controlled 300KN

Horizontal Universal Testing Machine Introduction :

The machine adopts the frame overall steel welding structure, single out the double-acting piston cylinder test force, cylindrical pin instrumentation sample, load sensor, according to the sample specification length can be adjusted step stretch space, computer screen test power and test curve, automatic processing according to the requirement of the test method of test data, the machine for lifting belt, chain and rope type do products by tensile test special equipment, used for hoisting belt products individually tensile load, destructive test, for convenient operation and slow loading smoothly, the body carrying capacity is strong, etc.

Detailed Specification :

Model No. PT-LEW-300
Machine Name Horizontal Universal Material Testing Machine Microcomputer Controlled 300KN
Max.Test Force 300KN
Measuring Force Range 60KN to 300KN
Test Force Resolution 1/300000 code
Test Force Accuracy 1%
Test Space (not including the piston stroke): 500-6000mm (500mm)
Piston Stroke 1000mm
Displacement Measurement Range 1000mm
Displacement Measurement Resolution 0.01mm
Pull Head No-Load Fast Forward Speed not less than 200mm/min
Test Speed 0-120mm/min;
Work Centre Height 350mm
Measuring Force Mode Load Sensor
Host Size

9000x1200x500mm (L*W*H)

Horizontal Testing Machine Picture :

Horizontal Universal Material Testing Machine Microcomputer Controlled 300KN Max Test Force

Machine Out Shape Picture :

Horizontal Universal Material Testing Machine Microcomputer Controlled 300KN Max Test Force
