Aluminium Frame Marquee Large Storage Tents Flame Retardant 40M x 140M
Aluminium Frame Marquee Large Storage Tents Flame Retardant 40M x 140M
Aluminium Frame Marquee Large Storage Tents Flame Retardant 40M x 140M
Aluminium Frame Marquee Large Storage Tents Flame Retardant 40M x 140M
Aluminium Frame Marquee Large Storage Tents Flame Retardant 40M x 140M
Aluminium Frame Marquee Large Storage Tents Flame Retardant 40M x 140M
Aluminium Frame Marquee Large Storage Tents Flame Retardant 40M x 140M
Aluminium Frame Marquee Large Storage Tents Flame Retardant 40M x 140M
Specifications
Brand Name :
Yashang
Model Number :
WAT19
Certification :
ISO, CE, TUV, COC, SONCAP etc.
Place of Origin :
China
Price :
negotiable
Payment Terms :
T/T, L/C, West Union, MoneyGram
Supply Ability :
5000~10000sqm per month
Packaging Details :
membrane film, PVC bags, steel cages
MOQ :
negotiable
Delivery Time :
45 work days
Framework :
Aluminium Lightweight Grid Structure
Cover :
Flame Retardant PVC Fabric 850gsm
Wind Load :
100km/h
Rain Gutter :
Metal Rain Gutter with Downspout
Gate :
20M Wide Open Door
Application :
Industrial space
Description

Aluminium Frame Marquee Large Storage Tents Flame Retardant 40M x 140M

The 5000 sqm large outdoor aluminum warehouse industrial storage tent is built for bonded logistics industry. The whole industrial logistics warehouse tent project is requested to be delivered and put into use in a short period of time. Thanks to its modular design and lightweight structure, the aluminum warehouse marquee is fast assembled. A 20M ultra wide 9M high customized door open as entrance.

Please contact with us directly to learn about the detailed specification of different tent projects, because the data in the form may not be updated in time.

Tent Size: 40m x 140m Tent Materials: Hard extruded aluminum alloy (framework)
Span Width: 40m Polyester textile fabric cover (top and wall)
Side Height: 4m Galvanized steel (connecting parts)
Top Height: 10.4m Tent Configurations: Aluminum framework
Bay Distance: 5m Fabric roof cover
Longest Part: 11.6m Transparent glass wall
Roof Pitch: 18° Glass door with canopy
Main Profile: 300 x 120 x 5mm Decorative lining system
Gable Post Profile: 203 x 112 x 4mm/166x88x3mm Energy-saving lighting system
Purlin Profile: 80 x 80 x 2mm Tent Packaging: Membrane film for long aluminum parts
Hang Tube Profile: 100 x 80 x 2mm PVC bags for fabric parts
Snow Load: 0.15kN/m² Steel cages for steel parts
Wind Load: 0.5kN/m² Tent Fixing Solution: Expansion screws for concrete ground (standard)
Tent Gross Weight: 49090kgs Steel peg nails for soft grass/sand land (optional)
Tent Total Volume: 147cbm Load Plate for undamagable ground (optional)
Setup Time: 8 people 5 to 6 days Installation Support: Installation instructional manual & video
Tent HS code:

6306220090

 On-site installation guide
Tent Lifespan: Aluminum part ≥ 25~30 years Factory installation training
PVC fabri ≥ 5~8years Free Tools Configured: Y-pole, Spanner, Ropes, Hammers, Ladders

Transparent PVC skylights are designed on roof fabric cover to enhance natural daylighting. Anti-collision columns are configured with the white industrial frame logistics warehouse canopy.

Aluminium Frame Marquee Large Storage Tents Flame Retardant 40M x 140M

The outdoor bonded logistics warehouse canopy is built as industrial shelter, only with aluminum framework and white fabric roof cover, no sidewall fabric. Solid metal rain gutter is configured at roof edge for better drainage and waterproof performance.

Aluminium Frame Marquee Large Storage Tents Flame Retardant 40M x 140M

The large Industrial aluminium warehouse structure is a flexible modular design, which can be fast set up and easily dismantled, and can be integrated with lighting systems and solid walls.

Aluminium Frame Marquee Large Storage Tents Flame Retardant 40M x 140M

Contact us now to know more details about the warehouse tent for bonded logistics industrial storage.
