20x35 M Clear Span Outdoor Event Tent Aluminium Frame Marquee Wind Resistance
20x35 M Clear Span Outdoor Event Tent Aluminium Frame Marquee Wind Resistance
20x35 M Clear Span Outdoor Event Tent Aluminium Frame Marquee Wind Resistance
20x35 M Clear Span Outdoor Event Tent Aluminium Frame Marquee Wind Resistance
20x35 M Clear Span Outdoor Event Tent Aluminium Frame Marquee Wind Resistance
20x35 M Clear Span Outdoor Event Tent Aluminium Frame Marquee Wind Resistance
20x35 M Clear Span Outdoor Event Tent Aluminium Frame Marquee Wind Resistance
20x35 M Clear Span Outdoor Event Tent Aluminium Frame Marquee Wind Resistance
Specifications
Brand Name :
Yashang
Model Number :
EVT02
Certification :
ISO, CE, TUV, COC, SONCAP etc.
Place of Origin :
China
Price :
negotiable
Payment Terms :
T/T, L/C, West Union, MoneyGram
Supply Ability :
5000~10000sqm per month
Delivery Time :
25 workdays
Packaging Details :
membrane film, PVC bags, steel cages
MOQ :
negotiable
Frame :
Aluminum Profiles
Cover :
850gsm PVC Fabric
Accessories :
Lighting, Carpet
Applications :
Corporate Events and Outdoor Activities
Connector :
Galvanized Steel
Wind Resistance :
100km/h
Tent Size :
20x35M
Fixing Solution :
Loading Plate and Decorated Weight Loads
Description

20x35 M Clear Span Outdoor Event Tent Aluminium Frame Marquee Wind Resistance

The 20x35m big white canopy aluminum frame tent is built for outdoor corporate events and sales promotional activities. Quality and safety always come first at Yashang. Yashang aluminum tent is the integrity and safety of all the materials and structures used. The structure meet stringent European requirements, including the German DIN standards. All the materials meet the highest European standard of fire safety. All structures are wind-resistant. In this way, Yashang ensures not only stylish tent but space solution as well.

Please contact with us directly to learn about the detailed specification of different tent projects, because the data in the form may not be updated in time.

Tent Size: 20m x 35m Tent Materials: Hard extruded aluminum alloy (framework)
Span Width: 20m Polyester textile fabric cover (top and wall)
Side Height: 4m Galvanized steel (connecting parts)
Top Height: 7.3m Tent Configurations: Aluminum framework
Bay Distance: 5m Fabric roof cover
Longest Part: 10.6m Fabric wall
Roof Pitch: 18° Energy-saving lighting system
Main Profile: 203 x 112 x 4mm Decorative lining system
Gable Post Profile: 166 x 88 x 3mm Glass door with canopy
Purlin Profile: 60 x 60 x 2mm Tent Packaging: Membrane film for long aluminum parts
Hang Tube Profile: 100 x 80 x 2mm PVC bags for fabric parts
Snow Load: 0.15kN/m² Steel cages for steel parts
Wind Load: 0.5kN/m² Tent Fixing Solution: Expansion screws for concrete ground (standard)
Tent Gross Weight: 5378kgs Steel peg nails for soft grass/sand land (optional)
Tent Total Volume: 17cbm Load Plate for undamagable ground (optional)
Setup Time: 8 people 1 to 2 days Installation Support: Installation instructional manual & video
Tent HS code:

6306220090

 On-site installation guide
Tent Lifespan: Aluminum part ≥ 25~30 years Factory installation training
PVC fabri ≥ 5~8years Free Tools Configured: Y-pole, Spanner, Ropes, Hammers, Ladders

To match large A-shape roof top aluminum marquee event tent, high peak pagoda tents of different sizes are usually configured as event reception space. In this tent, a 5x5m German style high peak pagoda tent is configured as supporting facility to the main event tent hall.

20x35 M Clear Span Outdoor Event Tent Aluminium Frame Marquee Wind Resistance

The large white event canopy is built on a scenic spot with a small portable aluminum ridge tent configured as a temporary warehouse for outdoor event items. Events in the aluminum frame tent will normally requires lighting system. The tent structure is strong enough that roof purlin can hang 100~150kgs at different positions.

20x35 M Clear Span Outdoor Event Tent Aluminium Frame Marquee Wind Resistance

Outdoor events will be held on different places, so the outdoor event tent need to be fixed into different ground conditions, using different fixation methods. In this tent project, the big event marquee canopy is held firmly onto ground by load plates.

Drawing on more than 12 years of designing and manufacturing aluminum tents, Yashang tents deserve your trust and your immediate purchase. Contact us now to find out more details on different tent fixing solutions...
