High Accuracy Hardness Testing Machine , Automatic Rockwell Hardness Tester
High Accuracy Hardness Testing Machine , Automatic Rockwell Hardness Tester
Specifications
Brand Name :
Trojan
Model Number :
560rssz
Certification :
CE
Place of Origin :
China
MOQ :
1
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
50000 Sets/Year
Delivery Time :
1-3 Working Days
Packaging Details :
Standard Export Package, Wooden Case
Port :
Shanghai, China
Type :
Rockwell Hardness Tester
Measuring Range :
HRC
Application :
Metal, Plastic
Standard :
ISO, ASTM, GB/T
Warranty :
1 Year
Mobility :
Desktop
Support Language :
English
Rated Voltage :
220V
Description

Product Description

High Accuracy Hardness Testing Machine , Automatic Rockwell Hardness Tester

High Accuracy Hardness Testing Machine , Automatic Rockwell Hardness Tester

Main Function

560RSSZ Automatic double Rockwell hardness tester with a good aesthetic aspect, complete functions, easy operation, intuitive display and good reliability, is a high-tech product combining the mechanic and electric features, which is suitable for the Rockwell and superficial Rockwell hardness test.

  1. Support for all the Rockwell and superficial Rockwell scales;
  2. Support for conversion scales of different kinds of hardness;
  3. Touch screen display and operation, dynamically display the working state of the lifting screw and the indenter;
  4. Press operation for the test table, fast rising or dropping;
  5. One key to complete the rising of the specimen, loading dwell and unloading of the indenter, displaying of the hardness value, homing of the test table;
  6. With data storage function, automatic calculation of the maximum, minimum, average of the hardness value, the test results can be printed for output, and with a RS232 interface users can connect it to the computer for output.

Application range

Suitable for quenched steel, tempered steel, annealed steel, cold and hard casting, malleable cast iron, hard alloy steel, aluminum alloy, copper alloy, bearing steel etc. Also suitable for surface quenched steel, surface heat treating and chemical treating materials, sheet, zinc layers, chrome layers, tin layers etc.

Technical Specification

Model 560RSSZ
Initial Test Force 3kgf (29.42N), 10kgf (98.07N)
Total Test Force 15kgf (147.1N), 30kgf (294.2N), 45kgf (441.3N), 60kgf (558.4N), 100kgf (980.7N), 150kgf (1471N)
Indenter Diamond Rockwell Indenter, ф1.588mmBall Indenter
Loading Method Automatic (Loading/Dwell/Unloading)
Automatic Test Table Automatic Rising and Homing, One Key to Complete
Hardness Reading Touch Screen
Test Scale HRA, HRD, HRC, HRF, HRB, HRG, HRH, HRE, HRK, HRL, HRM, HRP, HRR, HRS, HRV, HR15N, HR30N, HR45N, HR15T, HR30T, HR45T, HR15W, HR30W, HR45W, HR15X, HR30X, HR45X, HR15Y, HR30Y, HR45Y
Conversion Scale HV, HK, HRA, HRB, HRC, HRD, HRE, HRF, HRG, HRK, HR15N, HR30N, HR45N, HR15T, HR30T, HR45T, HBW
Data Output RS232 Interface
Resolution 0.1HR
Dwell Time 0~99s
Max. Height of Specimen 320mm
Throat 150mm
Power Supply AC220V, 50Hz
Execute Standard ISO 6508, ASTM E-18, JIS Z2245, GB/T 230.2
Dimension 535×330×890mm, Packing Dimension: 820×460×1170mm
Weight Net Weight: 80kg, Gross Weight: 100kg

Packing List

Name Qty Name Qty
Instrument Main Body 1 set Diamond Rockwell Indenter 1 pc
ф1.588mmBall Indenter 1 pc Middle Plane Test Table 1 pc
Large Plane Test Table 1 pc V-shaped Test Table 1 pc
Screwdriver 1 pc Spanner 1 pc
Hardness Block 60~70 HRC 1 pc Hardness Block 20~30 HRC 1 pc
Hardness Block 80~100 HRB 1 pc Hardness Block70~85 HR30T 1 pc
Hardness Block 65~80 HR30N 1 pc Fuse 2A 2 pcs
Power Cable 1 pc Anti-dust Cover 1 pc
Usage Instruction Manual 1 copy

Payment & Shiping

High Accuracy Hardness Testing Machine , Automatic Rockwell Hardness Tester
RFQ

1, Min. Order Quantity

1 piece is OK.

2. How about your technical team construction?

We have professional technicians team with 10 years' experience.

3, What's our warranty?

12 months

4, Ways of payment

T/T, L/C, Pay pal, Western Union

5, Ways of shipment

EXW, FOB, DHL, FedEx, or upon your requirements

6, Are you a trader or manufacture?

We are manufacturer, owns our factory in Suzhou.

7, Can you accept OEM or ODM?

Of course,Logo is also acceptable

8, What is the delivery time?

No special requirements, can be delivered within 3 days. For customized models, delivery time shall be discussed and confirmed according to order
