Specifications
Brand Name :
Infinity Machine
Model Number :
RS-8401 / RS-8401A
Certification :
CE, ISO
Place of Origin :
Made in China
MOQ :
1 set
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
200 sets per month
Delivery Time :
Shipped in 15 days after payment
Packaging Details :
Standard export wooden case with operation manual and video inside.
Capacity(optional) :
10kN,20kN,50kN
Unit(switchable) :
1/250,000
Stroke Resolution :
0.001mm
Motor :
AC servo motor/AC frequency control motor
Main Unit Dimension (W*D*H) :
1750*1000*2000mm or 1950*1200*2000mm
Main Unit Weight :
About 1250kg or 1550kg/About 1350kg or 1650kg
Power :
AC220V 5A or specified by user
Warranty :
1 year
Description

Honeycomb Box Compression Testing Machine / Servo Control Compression Tester for Paper Box

Model: RS-8401 / RS-8401A

Application:

Apply for compression resistance, deformation, stacking test of package container such as corrugated paper box and honeycomb box, and also the wooden package box.

Features:

High stability:

Adopt servo motor driver and gapless roll ball screw for transmission to eliminate noise and resonation; with timing belt transmission to get a accuracy location.

High precision:

Adopt highly precise explosion-proof loadcell,repeat tolerance: ±0.01%F.S.

Professional control software:

Servo motor control and computer professional software control. can do the compression strength test and the stacking test and get precise result. The software has the testing real-time graph, can set the test force, test displacement, and the force holding. Can output the professional test report with test results and test graphs, test report can be printed and also converted to be PDF format .

Specification:

Model RS-8401
Capacity (optional) 10KN, 20KN, 50KN
Unit (switchable) N, KN, Kgf, Lbf, Mpa,Lbf/In2, Kgf/mm2
Load resolution 1/250,000
Load accuracy ±1%
Test space 1000x1000x1200mm, 1200x1200x1200mm or 1500x1500x1500mm
Test speed 0.001~200mm/min
Stroke resolution 0.001mm
Software Special close-loop control software
Motor AC servo Motor
Dimension (WxDxH) 1750x1000x2000mm or 1950x1200x2000mm
Weight 1250Kg or 1550kg
Power supply AC220V 5A or specified by user
