Automatically Textile Testing Equipment Adjustable Heating Plate Height Sweating Guarded Hotplate 50 Hz
Automatically Textile Testing Equipment Adjustable Heating Plate Height Sweating Guarded Hotplate 50 Hz
Specifications
Brand Name :
TESTEX
Model Number :
TF129
Certification :
ISO 9001:2015
Place of Origin :
China
MOQ :
1
Price :
Negotiable
Payment Terms :
L/C,D/A,T/T,Western Union,MoneyGram, In Cash
Supply Ability :
300 Set/Sets per Month
Delivery Time :
30 days
Packaging Details :
Standard exporting wooden case
Temperature control accuracy :
± 0.03 oC
Air velocity :
0 ~ 1.2 m / s, adjustable
Temperature measurement :
± 0.01 oC
Sample thickness :
0~50mm
Dimensions :
1600 x 1300 x 1800 mm (L x W x H)
The sample platform lifts range :
0~50mm automatic lift
Description

Automatically Adjustable Heating Plate Height Sweating Guarded Hotplate 50 Hz

Application

Sweating Guarded Hotplate : Is a more professional, balanced and advanced Thermal and Evaporative Resistance test tool in the whole world.

The automatic water system, human skin simulation test plate, wind speed firm system, climate chamber, and test host are completely separated design. Automatically adjust the peak of the hotplate consistent with the thickness of the test example, make sure the wind sensor is 15mm atop the hotplate.

Windows-based software is obtainable. The most important machine inside the chamber is connected with the software by Wi-Fi, so operators can control and monitor the testing within the office. More so, an advanced Temperature & Humidity Chamber is obtainable with the machine.

Note: A customized PC is required for this tool.

Specifications

  • (RCT)Thermal resistance range: 0.002-2 .0 m²K / W

  • Repeatability: ≤ ± 2%

  • Resolution: 0.0001m²K / W

  • (Ret) evaporative Resistance range: 0-1000m²Pa / W

  • Repeatability: ≤ ± 2%

  • Resolution: 0.001m²· Pa / W

  • Test plate temperature range: 30 oC ~ 40 oC adjustable

  • Temperature control accuracy: ± 0.03 oC

  • Temperature measurement: ± 0.01 oC

  • Air velocity: 0 ~ 1.2 m / s, adjustable

  • Air velocity accuracy: ± 1%

  • The sample platform lifts range: 0~50mm automatic lift

  • Sample thickness: 0~50mm

  • Test plate area: 254mm x 254mm

  • Guard ring size: 512mm x 512mm

  • Guard ring width: 127mm

  • Weight: 600 kg

  • Power: 110V/220V 50 Hz

  • Dimensions: 1600 × 1300 ×1800 mm (L × W × H)

  • Standards: ISO 11092 ASTM F1868 ASTM D1518 GB/T 11048 JIS L1096-2010

Automatically Textile Testing Equipment Adjustable Heating Plate Height Sweating Guarded Hotplate 50 Hz
