Oil Bath Type Infrared Laboratory Dyeing Machine Textile Testing Machine
Oil Bath Type Infrared Laboratory Dyeing Machine Textile Testing Machine
Oil Bath Type Infrared Laboratory Dyeing Machine Textile Testing Machine
Oil Bath Type Infrared Laboratory Dyeing Machine Textile Testing Machine
Oil Bath Type Infrared Laboratory Dyeing Machine Textile Testing Machine
Oil Bath Type Infrared Laboratory Dyeing Machine Textile Testing Machine
Oil Bath Type Infrared Laboratory Dyeing Machine Textile Testing Machine
Oil Bath Type Infrared Laboratory Dyeing Machine Textile Testing Machine
Oil Bath Type Infrared Laboratory Dyeing Machine Textile Testing Machine
Oil Bath Type Infrared Laboratory Dyeing Machine Textile Testing Machine
Specifications
Brand Name :
GESTER
Model Number :
GT-D22
Certification :
CE, ISO
Place of Origin :
China
MOQ :
1 set
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
200 set/month
Delivery Time :
10-30 days
Packaging Details :
wooden packaging
Power :
AC220V
Usage :
dyeing and testing the color fastness of fabric
Product name :
ir dyeing machine
Warranty :
12 Months
Color :
Black
Description

Oil Bath Type Infrared Laboratory Dyeing Machine

Product Introduction

Application:

This Infrared Laboratory Dyeing Machine is oil bath type infrared laboratory dyeing machine, it combine the advantages of traditional glycerol dyeing machine with common infrared dyeing machine together. It’s apply to dyeing and testing the color fastness of the knitted fabric, woven fabric, yarn, cotton, loose fiber, zipper etc. It was special design for dyeing industry, chemical industry, raw material, cloth which can simulate the production conditions exactly and reach the process effect.

Feature

1. Easy to operate, dye pot can be individually Turn plate removed to save waiting time.
2. The ability to conduct the tests of various dyes and chemicals on dispersing, leveling,liquor ratio exhausting etc.
3. Special recommendation for “STEP DYEING”to select the best dyestuff and combinations for the most suitable dyeing curve to achieve the highest efficiency and quality.
4. Different sizes of dye pots for various weight of samples with yarn or fabric holders to ensure the good leveling result .There will be no crease mark.
5. Suitable for low liquor ratio dyeing. Sample weight from 4g to 20g.
6. Special design for humanity, durability and easy-maintenance.
7. Safe, high efficiency, environment friendly, energy saving, optimum for new dyeing small sample machines.

Key Specifications

Model GT-D22 A GT-D22 B
Staining cup number 12 24
Staining cup volume 300cc OR 425cc
Control mode LCD Microprocessor type, programmable process number: 100(0—99), 100 programmable steps per process
Heat method Infrared heat
Temperature range RT - 140 ℃
Temperature control accuracy ±0.2 ℃
Heating rate 0 - 3.5 ℃ / min
Cooling rate 0.2 - 5 ℃ / min
Cooling method Air-cooled
Rotation speed 0 - 60 rpm
Liquor ratio 1:5 -1:100
Power supply 1∮AC 220V 50/60HZ 3∮AC 380V 50/60HZ
Dimensions( L x W x H) 670×670×780mm 860×680×780mm
Weight 100kg 120kg

Standard Accessories:

Cups 1set Put the test sample.
Cups stand 1set Place where to put cups.
Protective glove 1set To avoid to be hurt by HT cups.
