P1210SVF1MB00 TIANMA LCD Panel 800*600 Pixels 12.1 Inch LCM Panel
P1210SVF1MB00 TIANMA LCD Panel 800*600 Pixels 12.1 Inch LCM Panel
P1210SVF1MB00 TIANMA LCD Panel 800*600 Pixels 12.1 Inch LCM Panel
P1210SVF1MB00 TIANMA LCD Panel 800*600 Pixels 12.1 Inch LCM Panel
P1210SVF1MB00 TIANMA LCD Panel 800*600 Pixels 12.1 Inch LCM Panel
P1210SVF1MB00 TIANMA LCD Panel 800*600 Pixels 12.1 Inch LCM Panel
P1210SVF1MB00 TIANMA LCD Panel 800*600 Pixels 12.1 Inch LCM Panel
P1210SVF1MB00 TIANMA LCD Panel 800*600 Pixels 12.1 Inch LCM Panel
Specifications
Brand Name :
TIANMA
Model Number :
P1210SVF1MB00
Place of Origin :
Shenzhen, China
Certification :
ISO 9241; IEC62341; JEITA CP-3451; ANSI/AAMI ES60601-1-2; IEC 60068
MOQ :
1 piece
Price :
Please contact us for latest price
Packaging Details :
Customized
Delivery Time :
1~7 working days
Payment Terms :
T/T, L/C, Credit card, PayPal
Supply Ability :
500,0 pieces per day
Size (inch) :
12.1
Resolution :
800*600
Brightness (cd/m²) :
500
Active Area (W*H) :
246×184.5
Outline Dimension (W*H*T) :
279x 209 x 9
Operating Temperature :
-20℃～70℃
Storage Temperature :
-30℃～80℃
Viewing angle(RLUD) :
88/88/88/88
View Direction :
IPS
Interface :
LVDS 20
Contrast Ratio :
1000
LED Lifetime (hrs) :
50K
Description

12.1 inch TFT LCD P1210SVF1MB00 TIANMA Display Panel 800*600 Pixels for Outdoor Applications

Product Description:

Brand TIANMA
Model P/N P1210SVF1MB00
Diagonal Size 12.1"
Panel Type a-Si TFT-LCD, LCM
Resolution 800(RGB)×600, SVGA 82PPI
Pixel Format RGB Vertical Stripe
Active Area 246(W)×184.5(H) mm
Bezel Opening 249.05(W)×188.3(H) mm
Outline Dim. 279(H)×209(V) ×9(D) mm
Luminance 500 cd/m² (Typ.)
View Direction Symmetry
Viewing Angle 88/88/88/88 (Typ.)(CR≥10)
Support Color 262K/16.7M 72% NTSC
Weight 492g (Typ.)
Frame Rate 60Hz
Interface Type LVDS (1 ch, 6/8-bit) , 20 pins Connector
Power Supply 3.3V (Typ.)
Treatment Antiglare
Contrast Ratio 1000:1 (Typ.) (TM)
Response Time 25 (Typ.)(Tr+Td)
Operating Mode SFT, Normally Black, Transmissive
Light Source WLED [8S4P] , 50K hours , With LED Driver
Designed For Outdoor application, construction or agriculture market
Touch Panel Without
Environment Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C

P1210SVF1MB00 TIANMA LCD Panel 800*600 Pixels 12.1 Inch LCM Panel

Features:

The TIANMA Display Panel features an IPS viewing direction, ensuring clear and consistent image quality from any angle. With a resolution of 800*600 and an active area of 246×184.5 (W*H), this LCD TFT module offers a high-quality display for medical applications.

Designed specifically for medical use, the TIANMA Display Panel is a reliable and durable option for healthcare professionals. Its LVDS interface allows for seamless integration into medical equipment, providing a smooth and efficient user experience.

Whether used for diagnostic imaging or surgical procedures, the TIANMA Display Panel provides exceptional image quality and clarity. Its high contrast ratio and IPS viewing direction make it an ideal choice for a wide range of medical applications.

Invest in the TIANMA Display Panel for your medical TFT display needs. Its superior image quality, LVDS interface, and LCD TFT module design make it a top choice for medical professionals.

Applications:

With a minimum order quantity of just one piece, the TIANMA P1210SVF1MB00 is a highly accessible and flexible option for companies looking to integrate a high-quality display panel into their products. Additionally, TIANMA's ISO 9241, IEC62341, JEITA CP-3451, ANSI/AAMI ES60601-1-2, and IEC 60068 certifications demonstrate the company's commitment to producing reliable and safe products.

The TIANMA P1210SVF1MB00 is suitable for use in a variety of product applications, including medical devices, industrial equipment, and automotive displays. Its wide operating temperature range of -20℃ to 70℃ and storage temperature range of -30℃ to 80℃ make it a reliable option for use in harsh environments.

TIANMA is a trusted and experienced player in the industrial TFT display panel market, and the P1210SVF1MB00 is a testament to the company's commitment to producing high-quality and reliable products.

P1210SVF1MB00 TIANMA LCD Panel 800*600 Pixels 12.1 Inch LCM Panel

P1210SVF1MB00 TIANMA LCD Panel 800*600 Pixels 12.1 Inch LCM Panel

Support and Services:

The TIANMA Display Panel product offers comprehensive technical support and services to ensure the optimal performance and longevity of the display. Our team of experts provides assistance with product selection, installation, and troubleshooting. We also offer ongoing maintenance and repair services to keep your display functioning at its best. Additionally, we provide training and education to help you maximize the potential of your TIANMA Display Panel product.

Packing and Shipping:

Product Packaging:

  • The TIANMA Display Panel is carefully packaged in a sturdy cardboard box.
  • The panel is wrapped in protective plastic to prevent any scratches or damage during shipping.
  • A foam layer is placed on top of the panel to provide extra cushioning.
  • The box is sealed with adhesive tape to ensure the safety of the product during shipping.

Shipping:

  • The TIANMA Display Panel is shipped through a trusted courier service.
  • The delivery time may vary depending on the location of the customer.
  • Customers will receive a tracking number to track the status of their shipment.
  • If there are any issues with the shipment, customers can contact our customer service team for assistance.
