Specifications
Brand Name :
BOE
Model Number :
GV101WUM-N40
Certification :
ISO 9241; IEC62341; JEITA CP-3451; ANSI/AAMI ES60601-1-2; IEC 60068
Place of Origin :
Shenzhen, China
MOQ :
1 piece
Price :
Please contact us for latest price
Payment Terms :
T/T, L/C, Credit card, PayPal
Supply Ability :
500,0 pieces per day
Delivery Time :
1~7 working days
Packaging Details :
Customized
Size (inch) :
10.1
Brightness (cd/m²) :
1000
Resolution :
1920×1200
Active Area (W*H) :
216.576×135.36
Outline Dimension (W*H*T) :
228.2×149
Operating Temperature :
-20 ~ 70 °C
Storage Temperature :
-30 ~ 80 °C
Viewing angle(RLUD) :
80/80/80/80
Viewing Direction :
IPS
Contrast Ratio :
1000
LED Lifetime (hrs) :
20K
Interface :
EDP 30
Description

10.1 inch BOE GV101WUM-N40 LCD Module Display with 1920×1200 Pixels Resolution 1000nit TFT High Brightness

Brand BOE
Model P/N GV101WUM-N40
Diagonal Size 10.1"
Panel Type a-Si TFT-LCD, Assembly
Resolution 1920(RGB)×1200, WUXGA 225PPI
Pixel Format RGB Vertical Stripe
Active Area 216.576(W)×135.36(H) mm
Bezel Opening -
Outline Size 228.2(W)×149(H)(D) mm
Luminance 1000 cd/m² (Typ.)
Viewing Angle 80/80/80/80 (Typ.)(CR≥10)
Good View at Symmetry
Color Depth 16.2M 50% NTSC
Mass 125±10g
Refresh Rate 60Hz
Treatment Hard coating (3H)
Contrast Ratio 1000 : 1 (Typ.) (TM)
Response 30 (Typ.)(Tr+Td) ms
Work Mode -
Backlight WLED , 20K hours , With LED Driver
Used for Industrial, Outdoor high brightness
Touchscreen Without
Signal Type eDP (2 Lanes) , eDP1.4 , HBR1 (2.7G/lane) , 30 pins Connector
Voltage Supply 3.8V (Typ.)
Max. Ratings Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C
