18.5 Inch DV185WHM-NM1 BOE Module 1366×768 Pixels 250nit LCD Panel
18.5 Inch DV185WHM-NM1 BOE Module 1366×768 Pixels 250nit LCD Panel
18.5 Inch DV185WHM-NM1 BOE Module 1366×768 Pixels 250nit LCD Panel
18.5 Inch DV185WHM-NM1 BOE Module 1366×768 Pixels 250nit LCD Panel
18.5 Inch DV185WHM-NM1 BOE Module 1366×768 Pixels 250nit LCD Panel
18.5 Inch DV185WHM-NM1 BOE Module 1366×768 Pixels 250nit LCD Panel
18.5 Inch DV185WHM-NM1 BOE Module 1366×768 Pixels 250nit LCD Panel
18.5 Inch DV185WHM-NM1 BOE Module 1366×768 Pixels 250nit LCD Panel
Specifications
Brand Name :
BOE
Model Number :
DV185WHM-NM1
Certification :
ISO 9241; IEC62341; JEITA CP-3451; ANSI/AAMI ES60601-1-2; IEC 60068
Place of Origin :
Shenzhen, China
MOQ :
1 piece
Price :
Please contact us for latest price
Payment Terms :
T/T, L/C, Credit card, PayPal
Supply Ability :
500,0 pieces per day
Delivery Time :
1~7 working days
Packaging Details :
Customized
Size (inch) :
18
Brightness (cd/m²) :
250
Resolution :
1366×768
Active Area (W*H) :
409.8×230.4
Outline Dimension (W*H*T) :
430.4×254.6×10.9
Operating Temperature :
0 ~ 50 °C
Storage Temperature :
-20 ~ 60 °C
Viewing angle(RLUD) :
89/89/89/89
Viewing Direction :
IPS
Contrast Ratio :
1000
LED Lifetime (hrs) :
30K
Interface :
LVDS 30
Description

18.5 inch DV185WHM-NM1 BOE Module with 1366×768 Pixels Resolution 250nit LCD Panel Type

BOE DV185WHM-NM1 Application Details
Basic Detail : Manufacturer BOE Model Name DV185WHM-NM1
Panel Type a-Si TFT-LCD , LCM Another Name
Panel Size 18.5 inch Designed For Medical Imaging,Digital Signage
Maximum Ratings : OP Temperature 0 ~ 50 °C ST Temperature -20 ~ 60 °C
RoHS RoHS Vibration Level 1.5G (14.7 m/s²)
Features : Srgb, WLED Backlight, Upside I/F,Matte
BOE DV185WHM-NM1 Optical Details
Basic Detail : Luminance 250 cd/m² (Typ.) Contrast Ratio 1000:1 (Typ.) (Transmissive)
Good View at Symmetry Response Speed 14 (Typ.)(G to G)
Viewing Angle 89/89/89/89 (Typ.)(CR≥10) Operating Mode ADS, Normally Black, Transmissive
Color Performance : Chromaticity Wx:0.313; Wy:0.329 Support Color 16.7M (6-bit + Hi-FRC)
Color Temperature 6485K White Variation 1.25/1.33 (Typ./Max.)(9 points)
1931 Color Gamut : NTSC Ratio 75% sRGB 99% coverage
Adobe RGB 77% coverage DCI-P3 78% coverage
Rec.2020 56% coverage Remarks sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)
BOE DV185WHM-NM1 Mechanical Details
Pixel Features : Number of Pixel 1366(RGB)×768, WXGA Arrangement RGB Vertical Stripe
Dot Pitch 0.100×0.300 (H×V) Pixel Pitch(W×H) 0.300×0.300 (H×V) [84PPI]
Physical Size : Active Viewing 409.8(H) × 230.4(V) Bezel Area(mm) 413.4(H) × 234.0(V)
(mm)
Outline Dim. 430.4(H) × 254.6(V) Depth(mm) 7.7/11.4 (Typ./Max.)
(mm)
Outline Features : Form Shape Flat Rectangle Orientation Landscape type
Aspect Ratio(W:H) 16:09 Shape Style
Fixation : Without
Other Detail : Mass 1.30Kgs (Typ.) Surface Antiglare (Haze 25%), Hard coating (3H)
