GV101WUM-N40 BOE LCD Display With 1280×800 12.1 Inch 450nit BOE Tft
GV101WUM-N40 BOE LCD Display With 1280×800 12.1 Inch 450nit BOE Tft
GV101WUM-N40 BOE LCD Display With 1280×800 12.1 Inch 450nit BOE Tft
GV101WUM-N40 BOE LCD Display With 1280×800 12.1 Inch 450nit BOE Tft
GV101WUM-N40 BOE LCD Display With 1280×800 12.1 Inch 450nit BOE Tft
GV101WUM-N40 BOE LCD Display With 1280×800 12.1 Inch 450nit BOE Tft
Specifications
Brand Name :
BOE
Model Number :
GV121WXM-N80
Certification :
ISO 9241; IEC62341; JEITA CP-3451; ANSI/AAMI ES60601-1-2; IEC 60068
Place of Origin :
Shenzhen, China
MOQ :
1 piece
Price :
Please contact us for latest price
Payment Terms :
T/T, L/C, Credit card, PayPal
Supply Ability :
500,0 pieces per day
Delivery Time :
1~7 working days
Packaging Details :
Customized
Size (inch) :
12.1
Brightness (cd/m²) :
450
Resolution :
1280×800
Active Area (W*H) :
262.565×164.16
Outline Dimension (W*H*T) :
278×184×9.91
Operating Temperature :
-20 ~ 70 °C
Storage Temperature :
-30 ~ 75 °C
Viewing angle(RLUD) :
85/85/85/85
Viewing Direction :
IPS
Contrast Ratio :
1000
LED Lifetime (hrs) :
20K
Interface :
LVDS 30
Description

12.1 inch GV101WUM-N40 BOE LCD Display with 1280×800 Pixels Liminance 450nit TFT LCD Module

BOE GV121WXM-N80 Application Details
Basic Info : Panel Brand BOE Panel Model GV121WXM-N80
Diagonal Size 12.1” Application Industrial
Panel Type a-Si TFT-LCD , LCM Model Alias -
Reliability : Operating Temp. -20 ~ 70 °C Storage Temp. -30 ~ 75 °C
RoHS State RoHS Vibration Level
Specific Features : WLED Backlight,With LED Driver
BOE GV121WXM-N80 Mechanical Details
Pixel Features : Pixel Format 1280(RGB)×800, WXGA Dot Pitch (W×H) 0.0684×0.2052 mm
Configuration RGB Vertical Stripe Pixel Pitch (W×H) 0.2052×0.2052 mm [123PPI]
Physical Size : Active Viewing 262.565(W)×164.16(H) mm Overall Dim. 278(W)×184(H) mm
Bezel Opening 264.66(W)×166.66(H) mm Overall Depth 6.76/9.91 (Typ./Max.) mm
Outline Features : Form Factor Flat Rectangle Orientation Landscape type
Aspect Ratio 16:10 Shape Style
Fixation : Side mounting holes (4-M3) on left, right bezel
Other Detail : Mass 535±27g Surface -
BOE GV121WXM-N80 Optical Details
Basic Information : Brightness 450 cd/m² (Typ.) Contrast Ratio 1000:1 (Typ.) (Transmissive)
Viewing Angle 85/85/85/85 (Typ.)(CR≥10) Optical Mode ADS, Normally Black, Transmissive
Viewing Direction Symmetry Response Time 30 (Typ.)(Tr+Td), 45 (Typ.)(G to G) ms
Color Performance : Chromaticity Wx:0.303; Wy:0.333 Color Numbers 16.7M (8-bit)
Color Temperature 6992K White Variation 1.33/1.43 (Typ./Max.)(9 points)
1931 Color Gamut : NTSC Ratio 52% sRGB 70% coverage
Adobe RGB 54% coverage DCI-P3 54% coverage
Rec.2020 39% coverage Remarks sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)
Dispaly Performance : Outdoor Visibility No Transmissivity 6.0% (Typ.)
