RoHS ST7701S Driver 360x640 3.0 Inch TFT LCD Displays
RoHS ST7701S Driver 360x640 3.0 Inch TFT LCD Displays
RoHS ST7701S Driver 360x640 3.0 Inch TFT LCD Displays
RoHS ST7701S Driver 360x640 3.0 Inch TFT LCD Displays
RoHS ST7701S Driver 360x640 3.0 Inch TFT LCD Displays
RoHS ST7701S Driver 360x640 3.0 Inch TFT LCD Displays
Specifications
Brand Name :
HSD
Model Number :
YT030H001
Certification :
RoHS
Place of Origin :
china
MOQ :
10pcs
Price :
USD 8.5-9/ PCS
Delivery Time :
20-25
Packaging Details :
50cm*50cm*60cm
Size :
3.0inch
Resolution :
360x (RGB) x 640
Interface :
RGB
Connect type :
FPC 0.5MM
Color Depth :
16.7M
Technology type :
a-Si
Pixel pitch (mm) :
0.102(W ) x 0.102(L)
Pixel Configuration :
R.G.B. Vertical Stripe
Display Mode :
Normally Black
Viewing Direction :
All O’clock
Description

RoHS ST7701S Driver 360x640 3.0 Inch TFT LCD Displays

YT030H001 is a color active matrix thin film transistor (TFT) liquid crystal display (LCD) that uses amorphous silicon TFT as a switching device. This TFT LCD has a 3.0(9:16) inch diagonally measured active display area with nHD (360 horizontal by 640 vertical pixel) resolution.

Product features

(1) Display type: 3.0 TFT; transmission normally black

(2) Display color: 262K / 65K

(3) Driver IC: st7701

(4) Backlight mode: white LED

Application

This product is used in mobile phones, handheld devices, POSS machines, police enforcement instruments, military handheld, automotive electronics, industrial equipment, medical equipment, smart home and other industries

General Specifications

NO. Item Specification Unit Remark
1 LCD Size 3.0 inch -
2 Panel Type IPS - -
3 Resolution 360x (RGB) x 640 pixel -
4 Display Mode Normally Black - -
5 Display Number of Colors 16.7M - Note
6 Viewing Direction VA - -
7 Contrast Ratio 600(min) - -
8 Luminance 300(TYP) cd/m2 Note
9 Module Size 43.44(W) ×75.31( L) ×2.65(T) mm Note
10 Active Area 36.72( W) × 65.28(L) mm -
11 Pixel Pitch 0.102(W ) x 0.102(L) mm -
12 Weight - g -
13 Driver IC ST7701S - -
14 Driver IC RAM Size RAMLess bit -
15 Light Source 6LEDs White - -
16 Interface SPI+SPI 18BIT - -
17 Operating Temperature -30~85 ºC -
18 Storage Temperature -30~85 ºC -

Outline Dimension (unit: mm)


RoHS ST7701S Driver 360x640 3.0 Inch TFT LCD Displays


Related Products

　 　 　 TFT-LCM(mm)　　 　 　 　 　
Size Model No. Resolution H V T Golden finger spacing Interface PIN IC
3 YT030H001 240x400 45.04 77.00 2.45 P0.8/W0.4 MCU16bit 37 ILI9327
3 YT030H001-V1 240x400 45.04 77.00 2.00 P0.8/W0.4 MCU16bit 37 ILI9327
3 YT030H001-V3 240x400 45.04 77.00 2.45 P0.8/W0.4 MCU8bit(高) 37 ILI9327
3 YT030H001-V4 240x400 45.04 77.00 2.45 P0.8/W0.4 MCU16bit 37 ILI9327
3 YT030HT001 240x400 45.04 77.00 3.40 P0.8/W0.4 MCU16bit 37 ILI9327
3 YT030HT001-V2 240x400 45.04 77.00 3.55 P0.8/W0.4 MCU8bit(高) 37 ILI9327
3 YT030H001-V5 240x400 45.04 77.00 3.40 P0.8/W0.4 MCU16bit 37 ILI9327
3 YT030HT001-V6 240x400 45.04 77.00 3.40 P0.8/W0.4 MCU8bit(低) 37 ILI9327

Exclusive features:


1. According to customer requirements custom structure, touch screen, FPC, configuration.
2. Accept small batch production, a full set of technical support services.

Why Choose us:

1.Our company established in 2011, and have a long-term cooperation with many well-known company

2.We have a professional r&d team and technical support

3.We have a large number of spot inventory and we can ship delivery asap after payment

4.We are direct agent of these brands,ordering process simple and delivery time short

5.All screen ship from our company has long warranty and we have enough technical support can provide

after-sales service
