LQ12X12 12.1 Inch 105PPI 1024×768 Sharp TFT LCD Display 245.76(H)×184.32(V) mm
LQ12X12 12.1 Inch 105PPI 1024×768 Sharp TFT LCD Display 245.76(H)×184.32(V) mm
LQ12X12 12.1 Inch 105PPI 1024×768 Sharp TFT LCD Display 245.76(H)×184.32(V) mm
LQ12X12 12.1 Inch 105PPI 1024×768 Sharp TFT LCD Display 245.76(H)×184.32(V) mm
LQ12X12 12.1 Inch 105PPI 1024×768 Sharp TFT LCD Display 245.76(H)×184.32(V) mm
LQ12X12 12.1 Inch 105PPI 1024×768 Sharp TFT LCD Display 245.76(H)×184.32(V) mm
Specifications
Brand Name :
SHARP
Model Number :
LQ12X12
Certification :
IS09001
Place of Origin :
Japan
MOQ :
1PCS
Payment Terms :
T/T IN ADVANCE, WESTERN UNION, PAYPAL, ESCROW
Supply Ability :
500PCS
Delivery Time :
Working Day:1-3 Days
Packaging Details :
Original Factory Package
Screen Size :
12.1 inch
Pixel Number :
1024(RGB)×768 [XGA] 105PPI
Active Area :
245.76(H)×184.32(V) mm
Environment :
0 ~ 50 °C
Type :
a-Si TFT-LCD , LCM
Configuration :
RGB Vertical Stripe
Outline Dim :
283(H)×215.6(V) ×17(D) mm
Treatment :
Antiglare, Hard coating (2H)
Light Source :
CCFL [2 pcs] , 10K hours , W/O Driver
Description

LQ12X12 12.1INCH SHARP TFT-LCD 1024(RGB)×768 [XGA] 105PPI PIXEL 0 ~ 50 °C Industrial LCD Panel

1. Main Information:

The LQ12X12 is a 12.1 inch diagonal a-Si TFT-LCD display panel product from Sharp Corporation (hereafter called Sharp), with an integral CCFL backlight system, without backlight driver, without touch screen. It features an operating temperature range of 0 ~ 50°C , a storage temperature range of -25 ~ 60°C . It's general features are summarized by Panelook in the following: Matte . Based on its features, Panelook recommend that this model be applied to Industrial etc

2. Sharp LQ12X12 Optical Details

Basic Information : Luminance 150 cd/m² (Typ.) Contrast Ratio 100 : 1 (Min.) (Transmissive)
Good View at 6 o'clock Response Speed 30/50 (Typ.)(Tr/Td) (ms)
Viewing Angle 35/35/10/30 (Min.)(CR≥10) Operating Mode TN, Normally White, Transmissive
Color Performance : Chromaticity Wx:0.290; Wy:0.320 Support Color 262K (6-bit)
Color Temperature 8022K White Uniformity 1.25 (Max.)(5 points)

3. Sharp LQ12X12 Mechanical Details

Pixel Features : Number of Pixel 1024(RGB)×768 [XGA] Arrangement RGB Vertical Stripe
Dot Pitch(W×H) 0.080×0.240 mm Pixel Pitch(W×H) 0.240×0.240 mm [105PPI]
Physical Size : Active Viewing 245.76(W)×184.32(H) mm Overall Dim. 283(W)×215.6(H) mm
Bezel Opening - Overall Depth 16.5±0.5 mm
Outline Features : Form Shape Flat Rectangle Orientation Landscape type
Aspect Ratio(W:H) 4:3 Shape Style -
Fixation : Face mounting holes (4-Φ3.4) on left, right bezel
Other Detail : Mass 1.14Kgs Surface Antiglare, Hard coating (2H)

4. Sharp LQ12X12 Lightting Details

Lamp Features: Lamp Shape Straight Lamp Type CCFL Position Edge light type (Top and Bottom)
Exchange - Amount 2 pcs Life 10K(Min.) (Hours)
Lamp Electrical : Input Current 2.5/5.5/6.0mA (Min./Typ./Max.) Input Voltage 530V (Typ.)
Frequency 40±10KHz Turn-on Voltage 1100/1400V (Max.)(Ta=+25/0℃)
Consumption 2.9W (Typ.)
Interface Features : Position - Physical Type Connector
Interface Detail : Brand Model Amount Pin Pitch Pin Amount Pin Assignment
JST BHR-03VS-1 2 pcs 4.0 mm 3 pins BLL-3PINS-HNL
Backlight Driver : No


5. FAQ:
Q1: What's the quality of your LCD Panel?

A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.

Q2: What is your return and refund policy?

A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.

Q3: How long is the lead time?

A: The lead time is about 1-3 working days after receipt of payment.

Q4: How can I get the quotation?

A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
