G084SN05 V5 AUO 8.4INCH 800×600RGB 350CD/M2 CCFL Analog + Digital Storage Temp.: -20 ~ 60 °C INDUSTRIAL LCD DISPLAY
G084SN05 V5 AUO 8.4INCH 800×600RGB 350CD/M2 CCFL Analog + Digital Storage Temp.: -20 ~ 60 °C INDUSTRIAL LCD DISPLAY
G084SN05 V5 AUO 8.4INCH 800×600RGB 350CD/M2 CCFL Analog + Digital Storage Temp.: -20 ~ 60 °C INDUSTRIAL LCD DISPLAY
G084SN05 V5 AUO 8.4INCH 800×600RGB 350CD/M2 CCFL Analog + Digital Storage Temp.: -20 ~ 60 °C INDUSTRIAL LCD DISPLAY
G084SN05 V5 AUO 8.4INCH 800×600RGB 350CD/M2 CCFL Analog + Digital Storage Temp.: -20 ~ 60 °C INDUSTRIAL LCD DISPLAY
G084SN05 V5 AUO 8.4INCH 800×600RGB 350CD/M2 CCFL Analog + Digital Storage Temp.: -20 ~ 60 °C INDUSTRIAL LCD DISPLAY
Specifications
Brand Name :
AUO
Model Number :
G084SN05 V5
Certification :
ISO9001
Place of Origin :
CHINA
MOQ :
1PCS
Payment Terms :
TT/PAYPAL/WESTERN UNION/ESCROW
Supply Ability :
200PCS
Delivery Time :
1-2 DAYS
Packaging Details :
30 pcs / box 405×328×301 mm
MODEL NUMBER :
G084SN05 V5
BRAND :
AUO
SIZE :
8.4INCH
RESOLUTION :
800×600 RGB
BRIGHTNESS :
350CD/M2
TEMPERATURE RANGE :
Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C
Description

AUO G084SN05 V5 Application Details

Basic Detail : Manufacturer Model Name G084SN05 V5
Panel Type a-Si TFT-LCD , LCM Another Name G084SN05 V.5
Panel Size 8.4 inch Designed For
Maximum Ratings : OP Temperature 0 ~ 50 °C ST Temperature -20 ~ 60 °C
Vibration Level 1.5G (14.7 m/s²) RoHS

AUO G084SN05 V5 Optical Details

Basic Information : Luminance 350 cd/m² (Typ.) Contrast Ratio 500 : 1 (Typ.) (Transmissive)
Good View at 12 o'clock Response Speed 10/25 (Typ.)(Tr/Td) (ms)
Viewing Angle 60/60/60/40 (Typ.)(CR≥10) Operating Mode TN, Normally White, Transmissive
Color Performance : Chromaticity Wx:0.310; Wy:0.330 Support Color 262K (6-bit)
Color Temperature 6638K White Uniformity 1.60 (Max.)(9 points)
1931 Color Gamlt : NTSC Ratio 46% sRGB 64% coverage
Adobe RGB 48% coverage DCI-P3 48% coverage
Rec.2020 35% coverage Remarks sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)

AUO G084SN05 V5 Mechanical Details

Pixel Features : Number of Pixel 800(RGB)×600 [SVGA] Arrangement RGB Vertical Stripe
Dot Pitch(W×H) 0.071×0.213 mm Pixel Pitch(W×H) 0.213×0.213 mm [119PPI]
Physical Size : Active Viewing 170.4(W)×127.8(H) mm Overall Dim. 203(W)×142.5(H) mm
Bezel Opening 173.6(W)×130.8(H) mm Overall Depth 6.7/12.7 (Typ./Max.) mm
Outline Features : Form Shape Flat Rectangle Orientation Landscape type
Aspect Ratio(W:H) 4:3 Shape Style
Fixation : Face mounting holes (2-Φ3.0, 2-R1.5) on left, right bezel
Other Detail : Mass 260±10g Surface -

AUO G084SN05 V5 Electronics Details

Refresh Rate : 60Hz
Reverse Scan : Yes (180°)
Power Consumption : 6.8W (Typ.)

AUO G084SN05 V5 Interface Details

Signal Electrical : Input Current 600/700mA (Typ./Max.) Input Voltage 3.3V (Typ.)
Consumption 1.98/2.31W (Typ./Max.) Signal Interface Analog RGB + TTL (1 ch, 6-bit)
Interface Features : Position - Physical Type Connector
Signal Interface : Brand Model Amount Pin Pitch Pin Amount Pin Assignment
Kyocera Elco 04-6274-036-000-800 1 pcs 0.5 mm 36 pins
HRS DF13B-9P-1.25V 1 pcs 1.25 mm 9 pins

AUO G084SN05 V5 Lightting Details

Lamp Features: Lamp Shape Straight Lamp Type CCFL Position Edge light type (Top and Bottom)
Exchange - Amount 2 pcs Life 50K(Typ.) (Hours)
Lamp Electrical : Input Current 4.0/6.0/7.0mA (Min./Typ./Max.) Input Voltage
Frequency 40/50/80KHz (Min./Typ./MAX.) Turn-on Voltage 670/870V (Max.)(Ta=+25/0℃)
Interface Features : Position - Physical Type Connector
Interface Detail : Brand Model Amount Pin Pitch Pin Amount Pin Assignment
JST BHR-03VS-1 2 pcs 4.0 mm 3 pins BLL-3PINS-HNL
Backlight Driver : No

FAQ:

Q1: What's the quality of your LCD Panel?

A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.

Q2: What is your return and refund policy?

A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.

Q3: How long is the lead time?

A: The lead time is about 1-3 working days after receipt of payment.

Q4: How can I get the quotation?

A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
