SP14N001-Z1 HITACHI 5.1 inch 240×128 150 cd/m² Storage Temp.: -20 ~ 70 °C INDUSTRIAL LCD DISPLAY
SP14N001-Z1 HITACHI 5.1 inch 240×128 150 cd/m² Storage Temp.: -20 ~ 70 °C INDUSTRIAL LCD DISPLAY
SP14N001-Z1 HITACHI 5.1 inch 240×128 150 cd/m² Storage Temp.: -20 ~ 70 °C INDUSTRIAL LCD DISPLAY
SP14N001-Z1 HITACHI 5.1 inch 240×128 150 cd/m² Storage Temp.: -20 ~ 70 °C INDUSTRIAL LCD DISPLAY
SP14N001-Z1 HITACHI 5.1 inch 240×128 150 cd/m² Storage Temp.: -20 ~ 70 °C INDUSTRIAL LCD DISPLAY
SP14N001-Z1 HITACHI 5.1 inch 240×128 150 cd/m² Storage Temp.: -20 ~ 70 °C INDUSTRIAL LCD DISPLAY
SP14N001-Z1 HITACHI 5.1 inch 240×128 150 cd/m² Storage Temp.: -20 ~ 70 °C INDUSTRIAL LCD DISPLAY
SP14N001-Z1 HITACHI 5.1 inch 240×128 150 cd/m² Storage Temp.: -20 ~ 70 °C INDUSTRIAL LCD DISPLAY
Specifications
Brand Name :
HITACHI
Model Number :
SP14N001-Z1
Certification :
ISO9001
Place of Origin :
JAPAN
MOQ :
1PCS
Payment Terms :
TT/PAYPAL/ESCROW/WESTERN UNION
Supply Ability :
400PCS
Packaging Details :
STANDARD PACKING
Delivery Time :
1-3 DAYS
MODEL NUMBER :
SP14N001-Z1
BRAND :
HITACHI
SIZE :
5.1INCH
RESOLUTION :
240×128 50PPI
BRIGHTNESS :
150 cd/m²
TEMPERATURE RANGE :
Operating Temp.: -10 ~ 60 °C ; Storage Temp.: -20 ~ 70 °C
Lamp Type :
WLED
SIGNAL LNTERFACE :
LVDS
Viewing Angle :
40 (Typ.)(CR≥2, Φ2-Φ1)
Description

HITACHI SP14N001-Z1 Application Details

Basic Information : Brand Model SP14N001-Z1
Type LCM FSTN-LCD Used For
Screen Size 5.1" Alias -
Environment : Storage Temp. -20 ~~ 70 °C Operating Temp. -10 ~~ 60 °C
RoHS Vibration 1.2G (11.76 m/s²)

HITACHI SP14N001-Z1 Mechanical Details

Pixel Features : Resolution 240×128 Dot Pitch(mm) 0.50×0.50 (H×V)
Pixel Format Rectangle Pixel Pitch(mm) 0.50×0.50 (H×V) [50PPI]
Mechanical Size : Active Area(mm) 119.98(H) × 63.98(V) Bezel Area(mm) 124.0(H) × 70.0(V)
Outline Dim.(mm) 159.4(H) × 101(V) Depth(mm) 11.0 (Max.)
Outline Features : Form Style Flat Rectangle Outline Shape
Aspect Ratio 17:9 (H:V) Orientation Landscape type
Mounting : Face mounting holes (2-Φ3.0, 2-R1.5)
Other Spec : Weight - Treatment Antiglare

HITACHI SP14N001-Z1 Optical Details

Basic Information : Luminance(cd/m²) 150 (Typ.) Contrast Ratio 20:1 (Typ.) (Transmissive)
Viewing Angle 40 (Typ.)(CR≥2, Φ2-Φ1) Display Mode STN, Black/White (Negative), Transmissive
Best View on 6 o'clock Response(ms) 120/150 (Typ.)(Tr/Td)
Color Performance : White Coordinate - Display Colors Monochrome
Color Temperature - White Uniformity 1.30 (Max.)(9 points)

HITACHI SP14N001-Z1 Electronics Details

Reverse Scan : No
Driver IC : Built-in T6963C
Driving Method : Duty: 1/128

HITACHI SP14N001-Z1 Interface Details

Signal Electrical : Voltage Supply 5.0V (Typ.) Current Supply 11.7mA (Typ.)
Signal Type : 8-bit parallel Signal Voltage -
Interface Features : Position - Type Connector
Interface Detail : Brand Model Quantity Pins Pitch Pin Configuration
1 pcs 26 pins 1.0 mm

HITACHI SP14N001-Z1 Backlight Details

Backlight Features: Shape - Type CCFL Position Edge light type
Replacement - Quantity 1 pcs Life Time -
Lamp Electrical : Voltage Supply 300V (Typ.) Current Supply 5.0±1mA
Frequency 70/85KHz (Typ./Max.) Startup Voltage 1000V (Min.)(Ta=+25℃)
Interface Features : Position - Type Connector
Interface Detail : Brand Model Quantity Pins Pitch Pin Configuration
JAE IL-G-4S-S3C2-SA 1 pcs 4 pins 2.5 mm BLL-4PINS-LNNH
Backlight Driver : No

whose pixels are arranged in Rectangle. As for mechanical detail, it features active area of 119.98(W)×63.98(H) mm, outline size of 159.4(W)×101(H)×11(D) mm, viewing area size of 124.0(W)×70.0(H) mm, with surface treament of Antiglare. As a STN, Black/White (Negative), Transmissive LCM product, SP14N001-Z1 can provides 150 cd/m² display brightness 20:1 transimissive contrast ratio, 40 (Typ.)(CR≥2, Φ2-Φ1) (L/R/U/D) viewing angle, best view direction on 6 o'clock , and response time of 120/150 (Typ.)(Tr/Td) ms., thus presenting a palette of Monochrome colors. This product adopted 1 pcs CCFL as it's backlight systerm which was placed as Edge light type, external backlight driver is additionally needed. SP14N001-Z1 utilizes 8-bit parallel as it's signal inputting systerm
