Specifications
Brand Name :
LG Display
Model Number :
LD880DEN-UKA2
Certification :
ISO9001
Place of Origin :
JAPAN
MOQ :
1PCS
Payment Terms :
TT/PAYPAL/ESCROW/WESTERN UNION
Supply Ability :
120PCS
Delivery Time :
1-2 DAYS
Packaging Details :
STANDARD PACKING
MODEL NUMBER :
LD880DEN-UKA2
BRAND :
LG Display
SIZE :
88INCH
BRIGHTNESS :
700CD/M2
Lamp Type :
WLED
RESOLUTION :
3840(RGB)×1080 45PPI
VIEWING ANGLEG :
89/89/89/89 (Typ.)(CR≥10)
TEMPERATURE RANGE :
Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C
Description

LG Display LD880DEN-UKA2 Application Details

Basic Information : Brand Model LD880DEN-UKA2
Type LCM a-Si TFT-LCD Used For




Screen Size 88" (Native bar) Alias LD880DEN (UK)(A2)
Environment : Storage Temp. -20 ~~ 60 °C Operating Temp. 0 ~~ 50 °C
RoHS Vibration -

LG Display LD880DEN-UKA2 Mechanical Details

Pixel Features : Resolution 3840(RGB)×1080 Dot Pitch(mm) 0.1865×0.554 (H×V)
Pixel Format RGB Vertical Stripe Pixel Pitch(mm) 0.554×0.554 (H×V) [45PPI]
Mechanical Size : Active Area(mm) 2148.48(H) × 598.32(V) Bezel Area(mm) 2149.5(H) × 599.4(V)
Outline Dim.(mm) 2158.3(H) × 611.2(V) Depth(mm) 38.3/84.2 (Typ./Max.)
Outline Features : Form Style Flat Rectangle Outline Shape
Aspect Ratio >3:1 (H:V) Orientation Landscape / Portrait
Other Spec : Weight 24.5Kgs Treatment Antiglare (Haze 3%), Hard coating (2H)

LG Display LD880DEN-UKA2 Optical Details

Basic Information : Luminance(cd/m²) 700 (Typ.) Contrast Ratio 1100:1 (Typ.) (Transmissive)
Viewing Angle 89/89/89/89 (Min.)(CR≥10) Display Mode IPS, Normally Black, Transmissive
Best View on Symmetry Response(ms) 8 (Typ.)(G to G)
Color Performance : White Coordinate X:0.279; Y:0.292 Display Colors 1.07B (10-bit)
Color Temperature 9972K White Uniformity 1.33 (Max.)(17 points)
1931 Color Gamlt : NTSC Ratio 74% sRGB 99% coverage
Adobe RGB 75% coverage DCI-P3 76% coverage
Rec.2020 55% coverage Remarks sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)
Dispaly Performance : Outdoor Visibility Sunlight Readable Transmissivity

LG Display LD880DEN-UKA2 Interface Details

Signal Electrical : Voltage Supply 12.0V (Typ.) Current Supply 1.22/1.59A (Typ./Max.)
Consumption 14.68/18.3W (Typ./Max.)
Signal Type : V-by-One 8 lane Signal Voltage -
Interface Features : Position - Type Connector
Interface Detail : Brand Model Quantity Pins Pitch Pin Configuration
JAE FI-RE51S-HF 1 pcs 51 pins 0.5 mm
YEONHO 20037WR-H05 1 pcs 5 pins 2.0 mm

LG Display LD880DEN-UKA2 Backlight Details

Backlight Features: Shape - Type WLED Position Direct light type
Replacement - Quantity - Life Time 50K(Min.) (Hours)
Interface Features : Position - Type Connector
Interface Detail : Brand Model Quantity Pins Pitch Pin Configuration
YEONHO 20022WR-H14B2 1 pcs 14 pins 2.0 mm
YEONHO 20022WR-H12B2 1 pcs 12 pins 2.0 mm
Backlight Driver : With LED Driver
Driver Electrical : Voltage Supply 24.0±2.4V Current Supply 17.3/19.0A (Typ./Max.)
Consumption 415.9/456.9W (Typ./Max.)

LG Display LD880DEN-UKA2 Packing Details

Package Box : Quantity Weight Box Size
4 pcs / box - 2360×760×665 mm (L×W×H)
