LW550PUL-HLA1 LG Display 55 1920(RGB)×1080 400 cd/m² INDUSTRIAL LCD DISPLAY
LW550PUL-HLA1 LG Display 55 1920(RGB)×1080 400 cd/m² INDUSTRIAL LCD DISPLAY
LW550PUL-HLA1 LG Display 55 1920(RGB)×1080 400 cd/m² INDUSTRIAL LCD DISPLAY
LW550PUL-HLA1 LG Display 55 1920(RGB)×1080 400 cd/m² INDUSTRIAL LCD DISPLAY
LW550PUL-HLA1 LG Display 55 1920(RGB)×1080 400 cd/m² INDUSTRIAL LCD DISPLAY
LW550PUL-HLA1 LG Display 55 1920(RGB)×1080 400 cd/m² INDUSTRIAL LCD DISPLAY
Specifications
Brand Name :
LG Display
Model Number :
LW550PUL-HLA1
Certification :
ISO9001
Place of Origin :
JAPAN
MOQ :
1PCS
Payment Terms :
TT/PAYPAL/ESCROW/WESTERN UNION
Supply Ability :
100PCS
Delivery Time :
1-2 DAYS
Packaging Details :
STANDARD PACKING
MODEL NUMBER :
LW550PUL-HLA1
BRAND :
LG Display
SIZE :
55 inch
BRIGHTNESS :
400CD/M2
Lamp Type :
WLED
RESOLUTION :
1920(RGBW)×1080 [FHD] 40PPI
VIEWING ANGLEG :
60/60/60/60 (Min.)
TEMPERATURE RANGE :
Operating Temperature: 0 ~ 45 °C ; Storage Temperature: -20 ~ 60 °C
Description

LG Display LW550PUL-HLA1 Application Details

Basic Information : Brand Model LW550PUL-HLA1
Type OLED AM-OLED Used For
Screen Size 55" Alias LW550PUL (HL)(A1)
Environment : Storage Temp. -20 ~~ 60 °C Operating Temp. 0 ~~ 45 °C

LG Display LW550PUL-HLA1 Mechanical Details

Pixel Features : Resolution 1920(RGBW)×1080, FHD Dot Pitch(mm) -
Pixel Format RGBW Vertical Stripe Pixel Pitch(mm) 0.630×0.630 (H×V) [40PPI]
Mechanical Size : Active Area(mm) 1209.6(H) × 680.4(V) Bezel Area(mm) -
Outline Dim.(mm) 1217.48(H) × 693.74(V) Depth(mm) 1.03 (Typ.)
Outline Features : Form Style Curved Display Outline Shape
Aspect Ratio 16:9 (H:V) Orientation Landscape type
Other Spec : Weight 2.40Kgs (Typ.) Treatment Hard coating (2H), Reflection 1.2% (Typ.)

LG Display LW550PUL-HLA1 Optical Details

Basic Information : Luminance(cd/m²) 400 (Typ.) Contrast Ratio 150000:1 (Typ.) (Transmissive)
Viewing Angle 60/60/60/60 (Min.) Display Mode -
Best View on Symmetry Response(ms) 1 (Typ.)(G to G); 8 (Typ.)(MPRT)
Color Performance : White Coordinate X:0.285; Y:0.294 Display Colors 1.07B (10-bit)
Color Temperature 9246K White Uniformity 1.25/1.43 (Typ./Max.)(9 points)
1931 Color Gamlt : NTSC Ratio 89% sRGB 100% coverage
Adobe RGB 86% coverage DCI-P3 93% coverage
Rec.2020 67% coverage Remarks sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)

LG Display LW550PUL-HLA1 Interface Details

Signal Electrical : Voltage Supply 12.0/24.0V (Typ.)(VDD/EVDD) Current Supply 1.61/3.23A (Typ.)(IDD/EIDD)
Consumption 19.32/77.52W (Typ.)(PDD/EPDD)
Signal Type : V-by-One 8 lane Signal Voltage -
Interface Features : Position - Type Connector
Interface Detail : Brand Model Quantity Pins Pitch Pin Configuration
YEONHO 20022WR-H14B2 1 pcs 14 pins 2.0 mm
JAE FI-RXE51S-HF 1 pcs 51 pins 0.5 mm

LG Display LW550PUL-HLA1 Packing Details

Package Box : Quantity Weight Box Size
70 pcs / box - 1440×1140×1085 mm (L×W×H)

FAQ:
Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
