LD650EQE-FJA1 LG Display 65 3840(RGB)×2160 500 cd/m² INDUSTRIAL LCD DISPLAY
LD650EQE-FJA1 LG Display 65 3840(RGB)×2160 500 cd/m² INDUSTRIAL LCD DISPLAY
LD650EQE-FJA1 LG Display 65 3840(RGB)×2160 500 cd/m² INDUSTRIAL LCD DISPLAY
LD650EQE-FJA1 LG Display 65 3840(RGB)×2160 500 cd/m² INDUSTRIAL LCD DISPLAY
LD650EQE-FJA1 LG Display 65 3840(RGB)×2160 500 cd/m² INDUSTRIAL LCD DISPLAY
LD650EQE-FJA1 LG Display 65 3840(RGB)×2160 500 cd/m² INDUSTRIAL LCD DISPLAY
Specifications
Brand Name :
LG DISPLAY
Model Number :
LD650EQE-FJA1
Certification :
ISO9001
Place of Origin :
JAPAN
MOQ :
1PCS
Payment Terms :
TT/PAYPAL/ESCROW/WESTERN UNION
Supply Ability :
300PCS
Delivery Time :
1-2 DAYS
Packaging Details :
STANDARD PACKING
MODEL NUMBER :
LD650EQE-FJA1
BRAND :
LG DISPLAY
SIZE :
65 inch
BRIGHTNESS :
500CD/M2
Lamp Type :
WLED
RESOLUTION :
3840(RGB)×2160, UHD, 68PPI
VIEWING ANGLEG :
89/89/89/89 (Typ.)(CR≥10)
TEMPERATURE RANGE :
Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C
Description

LG Display LD650EQE-FJA1 Application Details

Basic Detail : Manufacturer Model Name LD650EQE-FJA1
Panel Type a-Si TFT-LCD , LCM Another Name LD650EQE (FJ)(A1)
Panel Size 65 inch Designed For -
Maximum Ratings : OP Temperature 0 ~ 50 °C ST Temperature -20 ~ 60 °C

LG Display LD650EQE-FJA1 Optical Details

Basic Information : Luminance 500 cd/m² (Typ.) Contrast Ratio 1100 : 1 (Typ.) (Transmissive)
Good View at Symmetry Response Speed 8 (Typ.)(G to G) (ms)
Viewing Angle 89/89/89/89 (Min.)(CR≥10) Operating Mode IPS, Normally Black, Transmissive
Color Performance : Chromaticity Wx:0.279; Wy:0.292 Support Color 1.07B (8-bit + Dithering)
Color Temperature 9972K White Uniformity 1.33 (Max.)(9 points)
1931 Color Gamlt : NTSC Ratio 73% sRGB 96% coverage
Adobe RGB 74% coverage DCI-P3 75% coverage
Rec.2020 54% coverage Remarks sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)

LG Display LD650EQE-FJA1 Mechanical Details

Pixel Features : Number of Pixel 3840(RGB)×2160 [UHD] Arrangement RGB Vertical Stripe
Dot Pitch(W×H) 0.124×0.372 mm Pixel Pitch(W×H) 0.372×0.372 mm [68PPI]
Physical Size : Active Viewing 1428.48(W)×803.52(H) mm Overall Dim. 1452.2(W)×830(H) mm
Bezel Opening 1433.4(W)×808.6(H) mm Overall Depth 13.5 (Typ.) mm
Outline Features : Form Shape Flat Rectangle Orientation Landscape / Portrait
Aspect Ratio(W:H) 16:9 Shape Style
Other Detail : Mass 21.5/22.6Kgs (Typ./Max.) Surface Antiglare (Haze 28%), Hard coating (2H)

LG Display LD650EQE-FJA1 Interface Details

Signal Electrical : Input Current 1.32/1.72A (Typ./Max.) Input Voltage 12.0V (Typ.)
Consumption 15.84/20.59W (Typ./Max.) Signal Interface V-by-One 8 lane
Interface Features : Position Physical Type Connector
Signal Interface : Brand Model Amount Pin Pitch Pin Amount Pin Assignment
JAE FI-RE51S-HF 1 pcs 0.5 mm 51 pins

LG Display LD650EQE-FJA1 Lightting Details

Lamp Features: Lamp Shape - Lamp Type WLED Position Edge light type
Exchange - Amount - Life 50K(Typ.) (Hours)
Lamp Electrical : Input Current 90.2/95/99.7mA (MIn./Typ./Max.) Input Voltage 179±9V
Consumption 102.1W (Typ.)
Interface Features : Position - Physical Type Connector
Interface Detail : Brand Model Amount Pin Pitch Pin Amount Pin Assignment
UJU HS100-L08N-N62 1 pcs 1.0 mm 8 pins BLE-8PINS-CCCNNNNA
UJU HS100-L08N-N62-A 1 pcs 1.0 mm 8 pins BLE-8PINS-ANNNNCCC
Backlight Driver : No

LG Display LD650EQE-FJA1 Packing Details

Package Box : Amount Size (L×W×H) Weight
18 pcs / box 1700×1140×1090 mm -

Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
