LM265SQ1-SLA1 LG Display 26.5 1920(RGB)×1920 300 cd/m² INDUSTRIAL LCD DISPLAY
LM265SQ1-SLA1 LG Display 26.5 1920(RGB)×1920 300 cd/m² INDUSTRIAL LCD DISPLAY
LM265SQ1-SLA1 LG Display 26.5 1920(RGB)×1920 300 cd/m² INDUSTRIAL LCD DISPLAY
LM265SQ1-SLA1 LG Display 26.5 1920(RGB)×1920 300 cd/m² INDUSTRIAL LCD DISPLAY
LM265SQ1-SLA1 LG Display 26.5 1920(RGB)×1920 300 cd/m² INDUSTRIAL LCD DISPLAY
LM265SQ1-SLA1 LG Display 26.5 1920(RGB)×1920 300 cd/m² INDUSTRIAL LCD DISPLAY
Specifications
Brand Name :
LG DISPLAY
Model Number :
LM265SQ1-SLA1
Certification :
ISO9001
Place of Origin :
JAPAN
MOQ :
1PCS
Payment Terms :
TT/PAYPAL/ESCROW/WESTERN UNION
Supply Ability :
1000PCS
Delivery Time :
1-2 DAYS
Packaging Details :
STANDARD PACKING
MODEL NUMBER :
LM265SQ1-SLA1
TEMPERATURE RANGE :
Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C
VIEWING ANGLEG :
89/89/89/89 (Typ.)(CR≥10)
RESOLUTION :
1920(RGB)×1920, 102PPI
Lamp Type :
WLED
BRIGHTNESS :
300CD/M2
SIZE :
26.5 inch
BRAND :
LG DISPLAY
Description

LG Display LM265SQ1-SLA1 Application Details

Basic Info : Panel Brand Panel Model LM265SQ1-SLA1
Diagonal Size 26.5" Application








Panel Type a-Si TFT-LCD , LCM Model Alias LM265SQ1 (SL)(A1)
Reliability : Operating Temp. 0 ~ 50 °C Storage Temp. -20 ~ 60 °C

LG Display LM265SQ1-SLA1 Mechanical Details

Pixel Features : Pixel Format 1920(RGB)×1920 Dot Pitch 0.0826×0.2478 mm (H×V)
Configuration RGB Vertical Stripe Pixel Pitch 0.2478×0.2478 mm (H×V) [102PPI]
Mechanical Size : Display Area 475.776×475.776 mm (H×V) Bezel Area 479.0×479.0 mm (H×V)
Outline Dim. 491.8×491.8 mm (H×V) Outline Depth 8.4/13.1 (Typ./Max.) mm
Outline Features : Form Factor Flat Rectangle Orientation Landscape type
Aspect Ratio 1:1 (H:V) Shape Style
Holes & Brackets : Side mounting holes
Videowall Seam : 16.0 mm (Active to Active)
Other Features : Weight 2.21Kgs (Typ.) Surface Antiglare (Haze 25%), Hard coating (3H)

LG Display LM265SQ1-SLA1 Optical Details

Basic Information : Brightness 300 cd/m² (Typ.) Contrast Ratio 1000:1 (Typ.) (Transmissive)
Viewing Angle 89/89/89/89 (Typ.)(CR≥10) Optical Mode IPS, Normally Black, Transmissive
Viewing Direction Symmetry Response Time 14 (Typ.)(G to G) (ms)
Color Performance : Chromaticity Wx:0.313; Wy:0.329 Color Numbers 16.7M (8-bit)
Color Temperature 6485K White Uniformity 1.33 (Max.)(9 points)
1931 Color Gamlt : NTSC Ratio 76% sRGB 99% coverage
Adobe RGB 77% coverage DCI-P3 79% coverage
Rec.2020 57% coverage Remarks sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)

LG Display LM265SQ1-SLA1 Backlight Details

Back-light Features: Lamp Shape - Lamp Type WLED Life Time 30K(Min.) (Hours)
Replacement - Amount - Position Edge light type (Left side)
Lamp Electrical : Voltage Input 45.8±3V Current Input 120mA (Typ.)
Consumption 22/23.4W (Typ./Max.)
Interface Features : Type Connector Position Lamp Driver No
Interface Detail : Brand Model Pin Pitch Pins Amount Configuration
JST BM06B-SHJS-TB(HF) 1.0 mm 6 pins 1 pcs BLE-6PINS-CCAACC

LG Display LM265SQ1-SLA1 Interface Details

Signal Systerm : LVDS (4 ch, 8-bit) Logic Voltage -
Signal Electrical : Voltage Input 10V (Typ.) Current Input 610/760mA (Typ./Max.)
Consumption 6.1/7.6W (Typ./Max.)
Interface Features : Type Connector Position -
Connector Detail : Brand Model Pin Pitch Pins Amount Configuration
LS Mtron GT05P-51S-H38-E1500 0.5 mm 51 pins 1 pcs
LS Mtron GT05P-41S-H38-E1500 0.5 mm 41 pins 1 pcs

LG Display LM265SQ1-SLA1 Carton Details

Package Carton : Amount Net Weight Carton Size (L×W×H)
10 pcs / box - 562×362×560 mm

FAQ:
Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
