Specifications
Brand Name :
OEM, ODM All Available
Model Number :
KHSM303T
Certification :
CE,FC,RoHS
Place of Origin :
China
Size: :
97*57*59mm
Weight: :
300g
Type: :
night vision scope
Product number: :
KHSM303T
Power Adapter: :
5V/2A
Maximum adjustment height: :
30MOA
Operating temperature: :
-40℃~55℃
Description

Thermal Imaging Scope Digital Infrared Night Vision Riflescope With Reticle

Parameter:

Product number: KHSM303T
Sensor: 1/3”CMOS Sensor 1.2M pixel 1288X968
Display: 1.6 inch 640X480HD TFT
Lens Specifications: Focal length 20mm, F1.1
Magnification: 1 times (at a distance of 250mm for bright vision)
Field of View: Horizontal 7.4°×vertical 5.5° (1x state)
Standard Video Resolutions: 1920x1080P/30fps, 1280X720P/30fps, 848x480P/30fps
Video format: MP4
Segmented recording time: 5 minutes/10 minutes/15 minutes/30 minutes
Loop recording: support
Slideshow: support
RAM: Built-in 8GB memory card
boot time: less than 3s
Electronic amplification: Support digital continuous magnification, up to 8X
Video recording: support
Screen brightness adjustment: support
Image Color: Supports four image colors
Dash selection: Support, support 4 kinds of reticle
Reticle center calibration: support
time setting: support
language: Simplified Chinese, English and other six languages
type of battery: 16340/18350 Rechargeable Lithium Batteries (3.7V)
Power Adapter: 5V/2A
Charging time: less than 180 minutes
Charging status indication: support
Battery life: ≥3 hours
Battery indicator: support
Battery Tips: support
Timed shutdown: support
Data interface: Mini USB2.0 (charging/PC data connection)
Density adjustment amount/each coordinate value: 1/4 MOA
Maximum adjustment height: 30 MOA
Maximum adjustment width: 40 MOA
Operating temperature: -40℃~55℃
Storage temperature: -55℃~70℃
Shock: >=600G
waterproof level: IP67
weight: ≤300g
Dimensions: 97×57×59mm


Features:

Digital Nigh Vision Scope Features:
This product is a digital night vision scope that is the most advanced, exquisitely designed, powerful, simple and speedy, and can quickly and accurately target the target for shooting. It can also be used in a dark environment at night.

Power supply:

This product uses a 18650 large capacity rechargeable lithium battery.

Working time:

More than 6 hours when WiFi is turned on, and more than 8 hours when WiFi is turned off.
This machine comes with WiFi, which can be connected with the APP installed on the mobile device ( smartphone), and realize real-time image transmission video recording, photographing and other functions in the APP.

This product adopts 720P ultra low illumination detector.

This product is the best auxiliary tool for human vision extension. lf not clear enough, you need to turn on the infrared lighting flashlight at the night.

Use environment and precautions:


The night vision device should be stored in a soft bag.

The operating environment should be -30 to +55℃, and the relative humidity should not exceed 80%.

The night vision device should be stored in a clean and dry place to avoid damp, mold, heavy pressure, mechanical damage, humidity, and solar radiation.

Try to avoid rain or fog to prevent falling and bumping. When you find that the image on the display screen is shaking, the green grid lines or the screen does not light up, it indicates that the voltage is too low, and it needs to be charged in time.

If you need to clean the optical surface of the objective lens, eyepiece, and laser illuminator, you should first blow off small grit and dust, and then wipe the surface with a soft cloth.

If the night vision device is not used for a long time, please keep the battery charged frequently to prevent the rechargeable battery from failing.
