Uncooled FPA Thermal Imaging Module 50Hz Frame Rated UAV Drone Usage
Uncooled FPA Thermal Imaging Module 50Hz Frame Rated UAV Drone Usage
Specifications
Brand Name :
CONO
Model Number :
AXE6
Place of Origin :
China
MOQ :
1 PCS
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
1000 PCS PER YEAR
Delivery Time :
7-30 Days
Packaging Details :
Safety export packing
Original Place :
China
Model :
AXE6
Brand :
CONO
Name :
thermal camera module
Array format :
640*480
Noise reduce :
Digital filtering
Description

Uncooled FPA Thermal Imaging Module 50Hz Frame Rated UAV Drone Usage

Specification:

Model name AXE6
Detector
Array format 640*480
Pixel size 17μm
Detector Uncooled FPA
Spectral range 8~14μm
NETD ≤60mk@30℃
Boot up ≤3S
Calibration By shutter
Noise reduces Digital filtering
Image enhancement TIE thermal imaging enhance patented technology
Electric zoom 2X, 4X, 8X,digital zoom
Polarity reversal Available
Frame rate 50Hz
Display
Video output 50Hz(PAL )/ 60Hz(NTSC)
UVC USB video device class(USB2.0)
Palette 6 Palettes
Level adjustment Automatic/Manual
Brightness/Gain Automatic/Manual
OSD Firmware programmable, Full-screen overlay
Interface
Port RS485/232 optional
Power Available
USB interface Micro USB
Video Available
Keyboard control Optional
Power Supply
Operate voltage range DC 3~12V
USB power supply Yes
Power consumption <1.6W
Reverse connect protect Available
Over-voltage protection Available
Environment
Operating temp. -40℃~+60℃
Storage temp. -50℃~+85℃
Humidity ≤95% (non-condense)
Lens
Focal length (8mm, 10mm, 15mm, 19mm, 35mm, 50mm, 75mm, 100mm, 150mm) optional
Focus Fixed, manual, electric (optional)

Uncooled FPA Thermal Imaging Module 50Hz Frame Rated UAV Drone Usage

Uncooled FPA Thermal Imaging Module 50Hz Frame Rated UAV Drone Usage

Infrared Gallery

Uncooled FPA Thermal Imaging Module 50Hz Frame Rated UAV Drone Usage
