Polaris is featured with:
- Built-in laser rangefinder (optional)
- User freindsly menu
- Waterproof
- Built-in video recorder and WIFI connection
- Lightweight and compact design
High sensitive Thermal image sensor
The units have high sensitive thermal imaging sensor, this provides Polaris with the perfect detail recognition even when the thermal contrast of the suuroundings is low-during the snow, dust, smoke,fog,haze and other atmospheric obscurants.
IP67 protection range
IP67 waterproof-rated for protection from heavy rainfall, snow or other precipitation. The unit is designed to run flawlessly, even after submersion in up to 1 meter of water for up to 30 minutes.
Built-in laser rangefinder(Optional)
Polaris is capable of accurately measuring distance to objects up to 1000 meters away. The Integrated,precise laser rangefinder provides three modes -single time measurement, scanning mode and high-humidity mode.
1200G shock resistance
Polaris features high shock resistance and can be used with rifled hunting weapon for such cartridges as 9.3х64, .30-06, .300, .375. etc, and with smooth-bore and airsoft weapon.
Wifi and on-board recording
Built-in Wi-Fi module allows you to connect the Polaris with mobile units which enables you to receive footage in the real-time mode and save the image/video captured by the device.32 Gb of internal memory provides enough space for recording and taking photos of exciting moments.
Detection Range
A powerful F35 /1.1 or F50/1.1 objective lens combined with a 384x288@17µm highly-sensitive thermal imaging sensor provides exceptional detection capabilities.
Multiple palette
The 10-color palette enhances viewing in varying conditions.
Long lasting operation time
Polaris gives out long lasting operation time.External sources, such as power banks power bank with high-capacity is also capable of increasing the total operation time. 2 pcs of 18650 batteries meet the hunting needs of one night.
Polaris Technical Data Sheet | ||||||
Polaris 335R | Polaris 335RL | Polaris 350R | Polaris 350RL | Polaris 650R | Polaris 650RL | |
Detector | ||||||
Type | Uncooled Vox | Asi | ||||
Resolution | 384×288 | 640×480 | ||||
Frame rate | 50Hz | |||||
Pitch | 17μm | |||||
Spectral range | 8-14μm | |||||
NETD | Less than 50mk | |||||
Optical Characteristics | ||||||
Objective lens | 35mm/F1.1 | 50mm/F1.1 | 50mm/F1.1 | |||
Magnification | 1.9x | 2.7x | 2.4x | |||
FOV | 10.7°×8.0° | 7.5°×5.6° | 12.5°×9.4° | |||
Close-up range | 5m | |||||
Dioptre adjustment | -5D-4D | |||||
Functions | ||||||
Zoom | 2x/4x/PIP | |||||
Palette | 6 optional(can be customized) | |||||
Start up time | Less than 5 seconds | |||||
Start up image | Can be customized | |||||
Menu and information | GUI(Can be customized) | |||||
Image enhancement | DDE | |||||
Contrast and brightness | AGC | |||||
Online update | Both code and GUI resources | |||||
Display | ||||||
Type | OLED | |||||
Resolution | 1024×768 | |||||
External video | PAL,WIFI | |||||
Storage | 32G | |||||
Power Supply | ||||||
Battery | 2x18650 | |||||
External power supply | 5V micro USB | |||||
Working time with battery | 8h | 6h | ||||
Physical Characteristics | ||||||
Weight without battery | 618g | 688g | 650g | 720g | 630g | 700g |
Size | 180*76*83mm | 180*76*100mm | 196*76*83mm | 196*76*100mm | 188*76*83mm | 188*76*100mm |
Environmental Compatibility | ||||||
Water proof | IP67 | |||||
Operating temperature | -20℃-50℃ | |||||
Storage temperature | -40℃-60℃ | |||||
Laser Rangefinder(Optional) | ||||||
Safety class for laser equipment according to IEC 60825-1:2014 | 1 | |||||
Measuring range | 5-1000m | |||||
Measurement accuracy | ± 1m |
