Specifications
Brand Name :
Polywell
Model Number :
PW-CT002
Certification :
SGS
Place of Origin :
China
MOQ :
5000 meters
Price :
Negotiation
Payment Terms :
T/T, Western Union
Supply Ability :
100000 meters per day
Delivery Time :
10-15 working days
Packaging Details :
linear or roll
Product Name :
Extruded Nylon Thermal Break Strips for Aluminun Windows
Length :
6 meters or customized
Color :
Black
Size :
Customized
Port :
Shanghai
Application :
Thermal break aluminum
Density :
1.25-1.35 g/cm3
Refractoriness :
more than 240°C
OEM Service :
Available
Main Raw Material :
PA66GF25 material
Certificate :
SGS
Plastic Modling Type :
Extruding
Description
Customized Polyamide6.6 Thermal Break Strips Reinforced by Glass Fiber with density 1.3g/cm3

Product Description

What are the different types of polyamides?

Polyamide (PA) are among the most important and proven technical thermoplastics, known for their heat resistance, stiffness and high mechanical stability Polyamides can be classified into different types, with PA 6, PA 6.6 and PA 12 being the most established on the market.

Our polyamide strips are made of PA6.6 reinforced by 25% fiberglass.
Customized Polyamide6.6 Thermal Break Strips Reinforced by Glass Fiber with density 1.3g/cm3 Customized Polyamide6.6 Thermal Break Strips Reinforced by Glass Fiber with density 1.3g/cm3Customized Polyamide6.6 Thermal Break Strips Reinforced by Glass Fiber with density 1.3g/cm3 Customized Polyamide6.6 Thermal Break Strips Reinforced by Glass Fiber with density 1.3g/cm3

Product Performance

Item Unit GB/T 23615.1-2009 PW-Technical specification
Density g/cm3 1.3±0.05 1.28-1.35
Linear expansion coefficient K-1 (2.3-3.5)×10-5 (2.3-3.5)×10-5
Vicat softening temperature ºC ≥230 ≥233
Melting point ºC ≥240 ≥240
Testing for tensile cracks - No cracks No cracks
Shore hardness - 80±5 80-85
Impact strength(Unnotched) KJ/m2 ≥35 ≥38
Tensile strength(longitudinal) MPa ≥80a ≥82a
Elasticity modulus MPa ≥4500 ≥4550
Elongation at break % ≥2.5 ≥2.6
Tensile strength(transverse) MPa ≥70a ≥70a
High temperature tensile strength(transverse) MPa ≥45a ≥47a
Low temperature tensile strength(transverse) MPa ≥80a ≥81a
Water resistance tensile strength(transverse) MPa ≥35a ≥35a
Aging resistance tensile strength(transverse) MPa ≥50a ≥50a

1. Sample water content less than 0.2% by weight.
2. Norm laboratory condition:(23±2)ºC and (50±10)% relative humidity.
3. The specifications marked with "a" only applies to I-shape strip otherwise, the specifications concluded between supplier and buyer through consultation, shall be written in contract or purchase order.

Customized Polyamide6.6 Thermal Break Strips Reinforced by Glass Fiber with density 1.3g/cm3

Customized Polyamide6.6 Thermal Break Strips Reinforced by Glass Fiber with density 1.3g/cm3

Advantages

high quality, competitive price, free sample support and short lead time, high mechanical strength, high toughness, high softening point, good wear resistance, self-lubrication, long-term work at higher temperatures, high CTI value, excellent electrical insulation, low smoke and toxicity characteristics.

Customized Polyamide6.6 Thermal Break Strips Reinforced by Glass Fiber with density 1.3g/cm3

Package & Delivery

Packaging details: For all specifications/shapes, they could be packaged in linear, whose length will be 6 meters, or customized.

For the Shape "I", "C", and some simple shapes, they can be packed in rolls. 400-600 meters/roll.
Delivery details: shipped in 10–15 working days after receiving the deposit

Customized Polyamide6.6 Thermal Break Strips Reinforced by Glass Fiber with density 1.3g/cm3

Our Service

Before sales

1. introduce products in detail
2. recommend suitable solutions
3. provide with reference information

During manufacturing

1. provide with layout and engineering conditions
2. inform the processing status
3. offer related documents

After Sales

1. provide installation, commissioning and training
2. offer spare parts
3. Provide with necessary technical support

FAQ

  • About Sample
  • Sample is Free, but the express fee is collect or you pay us the cost in advance.
  • About MOQ
  • For the polyamide granules, MOQ is 1 ton. For the thermal break strips, MOQ is 5,000 meters.
  • About Customizing Special shape of polyamide Profiles and its period
  • You can customize the special shape of polyamide strips. If we didn't meet this shape before, we will make new mold for you, and you should pay for the mold.
  • About Customizing Package Style and Marks
  • You can customize the package style and marks.
  • Why your price is higher/lower than others?
  • For years specializing in polyamide granules and thermal break strips has bestowed us experienced and skilled technical workers and production workers. We promise the stability of products and the high-quality of raw material. Furthermore, we can provide technical support from raw material to the final appliance. Believe in that you can get better products and service with lower price.
  • About warranty
  • We are confident in our products, and pack them well before delivery, so usually you will receive your order in good condition. Any quality issue, we will deal with it immediately.
