3mm Thickness Thermal Gap Filler Pad 3mmT Ziitek TIF4120 For Heat Sinking Housing At LED-lit BLU in LCD
3mm Thickness Thermal Gap Filler Pad 3mmT Ziitek TIF4120 For Heat Sinking Housing At LED-lit BLU in LCD
3mm Thickness Thermal Gap Filler Pad 3mmT Ziitek TIF4120 For Heat Sinking Housing At LED-lit BLU in LCD
3mm Thickness Thermal Gap Filler Pad 3mmT Ziitek TIF4120 For Heat Sinking Housing At LED-lit BLU in LCD
Specifications
Brand Name :
ZIITEK
Model Number :
TIF™4120
Certification :
UL and RoHs
Place of Origin :
China
MOQ :
1000pcs
Price :
negotiation
Supply Ability :
100000pcs/day
Delivery Time :
3-5work days
Packaging Details :
1000pcs/bag
Color :
Yellow
Thickness :
3mmT
Product Name :
TIF4120
Fire rating :
94-V0
Description

2.0W /mK thermal gap filler pad 3mmT Ziitek TIF4120 for Heat Sinking Housing at LED-lit BLU in LCD

Company Profile
Ziitek company is a manufacturer of thermal conductive gap fillers, low melting point thermal interface materials, thermal conductive insulators, thermally conductive tapes, electrically & thermally conductive Interface pads and thermal grease,Thermal Conductive plastic,Silicone Rubber,Silicone Foams,Phase Changing Materials products, with well-equipped testing equipment and strong technical force.

The TIF™ 4120 is a silicone based, thermally conductive gap pad. Its unreinforced construction allows additional compliancy. This product has low hardness is conformable and is electrically isolating. The low modulus characteristic of the product offers optimal thermal performance with the ease of handling
Features:
> Good thermal conductive: 2 W/mK
> Thickness: 3mmT
> Naturally tacky needing no further adhesive coating
> Soft and Compressible for low stress applications
Applications:
> Cooling components to the chassis of frame
> High speed mass storage drives
> Heat Sinking Housing at LED-lit BLU in LCD
> LED TV and LED-lit lamps
> RDRAM memory modules
> Micro heat pipe thermal solutions
> Automotive engine control units
> Telecommunication hardware
> Handheld portable electronics
> Semiconductor automated test equipment (ATE)

Typical Properties of TIF™4120
Color

Yellow

VisualComposite ThicknesshermalImpedance
@10psi
(℃-in²/W)
Construction &
Compostion
Ceramic filled silicone rubber
***10mils / 0.254 mm

0.57

20mils / 0.508 mm

0.71

Specific Gravity

2.5 g/cc

ASTM D297

30mils / 0.762 mm

0.88

40mils / 1.016 mm

0.96

Heat Capacity

1 l/g-K

ASTM C351

50mils / 1.270 mm

1.11

60mils / 1.524 mm

1.26

Hardness
45 Shore 00ASTM 2240

70mils / 1.778 mm

1.39

80mils / 2.032 mm

1.54

Tensile Strength

48 psi

ASTM D412

90mils / 2.286 mm

1.66

100mils / 2.540 mm

1.78

Continuos Use Temp
-50 to 200℃

***

110mils / 2.794 mm

1.87

120mils / 3.048 mm

1.99

Dielectric Breakdown Voltage>1500～>5500 VACASTM D149

130mils / 3.302mm

2.12

140mils / 3.556 mm

2.22

Dielectric Constant
10.2 MHzASTM D150

150mils / 3.810 mm

2.31

160mils / 4.064 mm

2.41

Volume Resistivity7.3X10"
Ohm-meter		ASTM D257

170mils / 4.318 mm

2.51

180mils / 4.572 mm

2.58

Fire rating
94 V0

equivalent UL

190mils / 4.826 mm

2.64

200mils / 5.080 mm

2.72

Thermal conductivity
 2 W/m-KASTM D5470Visua l/ ASTM D751ASTM D5470
Standard Thicknesses:

0.120" (3.05mm)

Standard Sheets Sizes:

8" x 16"(203mm x 406mm) 16" x 18"(406mm x 457mm)
TIF™ series Individual die cut shapes can be supplied.

Peressure Sensitive Adhesive:

Request adhesive on one side with "A1" suffix.
Request adhesive on double side with "A2" suffix.

Reinforcement:

TIF™ series sheets type can add with fiberglass reinforced.

Certifications:

ISO9001:2015

ISO14001: 2004 IATF16949:2016

IECQ QC 080000:2017

UL

3mm Thickness Thermal Gap Filler Pad 3mmT Ziitek TIF4120 For Heat Sinking Housing At LED-lit BLU in LCD


Advantage

Ziitek has independent R&D team. This team is experience, rigorous and pragmatic.
They undertake the core research and development tasks of Ziitek thermal conductive materials. With well-equipped testing equipment, we Ziitek can also do some tests with customers' samples, so we can find a more suitable Ziitek materials for every customer.

FAQ

Q:How can we get detailed price list?
A:Please offer us detailed information of the product such as Size(length,width,thickness),color,specific packaging requirements and purchasing quantity.
Q: What kind of packaging you offer?
A: During the packaging process, preventive measures will be taken by us to assure that the goods are in a good condition during storage and delivery.

Q:Do big buyers have promotional prices?
A: Yes, if you are a big buyer in a certain area, Ziitek will provide you with promotional prices, which will help you start your business here. Buyers with long-term cooperation will have better prices.

Q:Is there promotion price for big buyer?
A:Yes, we do have promotion price for big buyer. Please send us email for inquiry.
