Insulation Silicone Thermal Pad Conductive Gap Filler Thermal Pad For Ev Battery Cooling
Insulation Silicone Thermal Pad Conductive Gap Filler Thermal Pad For Ev Battery Cooling
Insulation Silicone Thermal Pad Conductive Gap Filler Thermal Pad For Ev Battery Cooling
Insulation Silicone Thermal Pad Conductive Gap Filler Thermal Pad For Ev Battery Cooling
Specifications
Brand Name :
ZIITEK
Model Number :
TIF200-02E
Certification :
UL and RoHs
Place of Origin :
China
MOQ :
1000pcs
Price :
negotiation
Supply Ability :
100000pcs/day
Delivery Time :
3-5 work days
Packaging Details :
1000pcs/bag
Products name :
Insulation Silicone Thermal Pad Conductive Gap Filler Thermal Pad For Ev Battery Cooling
Color :
Pink
Thermal conductivity :
1.25 W/m-K
Hardness :
35 Shore 00
Specific Gravity :
2.2g/cc
Dielectric Constant :
4.0 MHz
Continuos Use Temp :
-45 to 200℃
Keywords :
Thermal Pad
Description

Insulation Silicone Thermal Pad Conductive Gap Filler Thermal Pad For Ev Battery Cooling

Ziitek company is a manufacturer of thermal conductive gap fillers, low melting point thermal interface materials, thermal conductive insulators, thermally conductive tapes, electrically & thermally conductive Interface pads and thermal grease,Thermal Conductive plastic, Silicone Rubber,Silicone Foams,Phase Changing Materials products, with well-equipped testing equipment and strong technical force.

The TIF™200-02E is not only designed to take advantage of the gap heat transfer, to fill gaps, complete the heat transfer between heating and cooling parts, but also played insulation, damping, sealing and so on, to meet the equipment miniaturization and ultra-thin design Requirements, which is a highly technology and use, and the thickness of the wide range of applications, is also an excellent thermal conductivity filler material.

Features

> Good thermal conductive
> Moldability for complex parts
> Soft and compressible for low stress applications
> Naturally tacky needing no further adhesive coating
> Available in varies thicknesses
> Broad range of hardnesses available

Applications

> CPU
> display card
> mainboard/mother board
> notebook
> power supply
> Heat pipe thermal solutions
> Memory Modules
> Mass storage devices
> Automotive electronics
> Set top boxes
> Audio and video components

Typical Properties of TIF200-02E
Color PINK Visual
Construction &Compostion Ceramic filled silicone elastomer *****
Specific Gravity 2.2 g/cc ASTM D297
Hardness 35 Shore 00 ASTM 2240
Thickness range 0.020"(0.5mm)~0.200“(5.0mm) ASTM D374
Continuos Use Temp -45 to 200℃ *****
Dielectric Breakdown Voltage >5500 VAC ASTM D149
Dielectric Constant 4.0 MHz ASTM D150
Volume Resistivity 1.0X10¹² Ohm-cm ASTM D257
Fire rating 94 V0 equivalent UL
Thermal conductivity 1.25 W/m-K ASTM D5470

Standard Sheets Sizes:
8" x 16"(203mm x 406mm)
TIF™ series Individual die cut shapes can be supplied.

Peressure Sensitive Adhesive:
Request adhesive on one side with "A1" suffix.
Request adhesive on double side with "A2" suffix.
Insulation Silicone Thermal Pad Conductive Gap Filler Thermal Pad For Ev Battery Cooling

Packaging Details & Lead time

The packaging of thermal pad

1.with PET film or foam-for protection

2. use Paper Card To Separate Each Layer

3. export carton inside and outside

4. meet with customers' requirement-customized

Lead Time :Quantity(Pieces):5000

Est. Time(days): To be negotiated

Ziitek Culture

Quality :

Do it right the first time, total quality control

Effectiveness:

Work precisely and thoroughly for effectiveness

Service:

Quick response, On time delivery and Excellent service

Team work:

Complete teamwork, including sales team, Marketing team, engineering team, R&D team, Manufacturing team, logistics team. All is for supporting and servicing a satisfy service for customers.
