Excellent Thermal Conductive Plastic for LED Lamp Cup 150℃ Heat Deflection Temperature TCP™100-50-01A
Excellent Thermal Conductive Plastic for LED Lamp Cup 150℃ Heat Deflection Temperature TCP™100-50-01A
Excellent Thermal Conductive Plastic for LED Lamp Cup 150℃ Heat Deflection Temperature TCP™100-50-01A
Excellent Thermal Conductive Plastic for LED Lamp Cup 150℃ Heat Deflection Temperature TCP™100-50-01A
Excellent Thermal Conductive Plastic for LED Lamp Cup 150℃ Heat Deflection Temperature TCP™100-50-01A
Excellent Thermal Conductive Plastic for LED Lamp Cup 150℃ Heat Deflection Temperature TCP™100-50-01A
Excellent Thermal Conductive Plastic for LED Lamp Cup 150℃ Heat Deflection Temperature TCP™100-50-01A
Excellent Thermal Conductive Plastic for LED Lamp Cup 150℃ Heat Deflection Temperature TCP™100-50-01A
Specifications
Brand Name :
Ziitek
Model Number :
TCP100-50-01A
Certification :
RoHs and UL
Place of Origin :
China
MOQ :
100kg
Supply Ability :
1000KG/day
Packaging Details :
25KG/Bag
Shrinkage :
0.1%
Thermal Conductivity In Plane :
5.0W/mK
Thermal Conductivity Throngh Plane :
15W/mK
Heat Deflection Temperature :
150℃
Specific Gravity :
1.45g/cm3
Color :
Black
Description
Excellent Thermal Conductive Plastic for LED Lamp Cup 150℃ Heat Deflection Temperature
Company Profile
With a wide range, good quality, reasonable prices and stylish designs, Ziitek thermal conductive interface materials are extensively used in Mainboards, VGA cards, Notebooks, DDR&DDR2 products, CD-ROM ,LCD TV, PDP products, Server Power products, Down lamps, Spotlights, Street lamps, Daylight lamps, LED Server Power products and others.
Excellent Thermal Conductive Plastic for LED Lamp Cup 150℃ Heat Deflection Temperature TCP™100-50-01A

TCP™100-50-01A is a Thermally Conductive Engineering Plastic developed for the housing design which requires high thermally conductivity and reduces the weight more than 30% comparing with the same aluminium devices.

Application

TCP™100-50-01A can be used in applications such as Heat Sinking Housing at LED-lit BLU in LCD/LED TV and LED-lit lamps such as MR16. Also it can replace the normal Aluminum heat sink.

Features

> Good thermal conductivity: 5.0W/mK
> Excellent thermal conductivity compared to normal engineering plastics
> Lighter than normal Aluminum housing 30% in weight
> Excellent mould ability in injection moulding
> Much higher production yield than normal Aluminum Die Casting
> Excellent flexibility in designing final products such as housings.
> UL94 V-0.
Typical Properties of TCPTM100-50-01A
Items Test method Unit Typical data
Physical Properties
Color Visual ***** Black
Melt index ISO 1133 g/10min 4
Specific Gravity ISO 1183 g/cm3 1.45
Shrinkage ISO 294 % 0.1
Mechanical Properties
Tensile Strength ISO 527 MPa 55
Flexural Strength ISO 178 MPa 80
Flexural Modulus ISO 178 MPa 15800
Impact Strength, notched ISO 180 kJ/m2 2.5～3.5
Electrical Properties
Dielectric Constant, 1MHz ASTM D150 ***** 4.5
Volume Resistivity ASTM D257 Ohm-meter 10000
Thermal Properties
Heat Deflection Temperature ASTM D648 ℃ 150
Thermal Conductivity In Plane ASTM E1461 W/m-K 15
Thermal Conductivity Throngh Plane ASTM E1461 W/m-K 5.0
Flame retardancy Min. thick. 1.0mm Class V-0

a. Pre-Drying : 4 hrs. @ 80℃ by Hopper Dryer

b. Recommendable Process Temperature at molding machine
- Nozzie : 280℃
- Front : 270℃
- Middle : 260℃
- Rear : 250℃
c. Cycle time : 30sec
Excellent Thermal Conductive Plastic for LED Lamp Cup 150℃ Heat Deflection Temperature TCP™100-50-01A

Why Choose us ?

1.Our value message is'' Do it right the First time, total quality control''.
2.Our core competencies is thermal conductive interface materials
3.Competitive advantage products.
4.Condidentiality agreement Bussiness Secrect Contract
5.Free sample offer
6.Quality assurance contract
