5W / MK Thermal Conductive Gap Pad 1.0mmT 45 SHORE00 For LED Floor Light
5W / MK Thermal Conductive Gap Pad 1.0mmT 45 SHORE00 For LED Floor Light
5W / MK Thermal Conductive Gap Pad 1.0mmT 45 SHORE00 For LED Floor Light
5W / MK Thermal Conductive Gap Pad 1.0mmT 45 SHORE00 For LED Floor Light
5W / MK Thermal Conductive Gap Pad 1.0mmT 45 SHORE00 For LED Floor Light
5W / MK Thermal Conductive Gap Pad 1.0mmT 45 SHORE00 For LED Floor Light
5W / MK Thermal Conductive Gap Pad 1.0mmT 45 SHORE00 For LED Floor Light
5W / MK Thermal Conductive Gap Pad 1.0mmT 45 SHORE00 For LED Floor Light
Specifications
Brand Name :
ZIITEK
Model Number :
TIF540-50-11S
Certification :
UL and RoHs
Place of Origin :
China
MOQ :
1000pcs
Price :
negotiation
Supply Ability :
10000/day
Delivery Time :
3-5work days
Packaging Details :
1000pcs/bag
Thermal conductivity& Compostion :
5.0W/m-K
Color :
grey
branch name :
ZIITEK
Hardness :
45 SHORE00
application :
Rainproof LED Power
Thickness :
1.0mmT
Description

5W / MK thermal conductive gap pad TIF540-50-11S,1.0mmT,45 SHORE00 for LED floor light

The TIF540-50-11US is not only designed to take advantage of the gap heat transfer, to fill gaps, complete the heat transfer between heating and cooling parts, but also played insulation, damping, sealing and so on, to meet the equipment miniaturization and ultra-thin design Requirements, which is a highly technology and use, and the thickness of the wide range of applications, is also an excellent thermal conductivity filler material.

TIF500-50-11S Datasheet-REV02.pdf


Features:


> Good thermal conductive: 5.0W/mK

>Thickness:1.0mmT

>RoHS compliant

>Easy release construction

>Outstanding thermal performance

>Naturally tacky needing no further adhesive coating

Applications:

>LED floor light

>Routers

>notebook

>power supply

>Heat pipe thermal solutions

>RDRAM memory modules

>Micro heat pipe thermal solutions

>Automotive engine control units

Typical Properties of TIF540-50-11S
Color

Grey

 Visual Composite Thickness hermalImpedance
@10psi
(℃-in²/W)
Construction &
Compostion		 Ceramic filled silicone rubber *** 10mils / 0.254 mm 0.21
20mils / 0.508 mm 0.27
Specific Gravity 3.15 g /cc ASTM D297

30mils / 0.762 mm

 0.39

40mils / 1.016 mm

 0.43
Thichness 1.0mmT ***

50mils / 1.270 mm

 0.50

60mils / 1.524 mm

0.58
Hardness 45 Shore 00 ASTM 2240

70mils / 1.778 mm

 0.65

80mils / 2.032 mm

 0.76
Tensile Strength

55 ps

 ASTM D412

90mils / 2.286 mm

 0.85

100mils / 2.540 mm

 0.94
Continuos Use Temp -40 to 160℃

***

110mils / 2.794 mm

 1.00

120mils / 3.048 mm

 1.07
Dielectric Breakdown Voltage >5500 VAC ASTM D149

130mils / 3.302mm

 1.16

140mils / 3.556 mm

 1.25
Dielectric Constant 4.0 MHz ASTM D150

150mils / 3.810 mm

 1.31

160mils / 4.064 mm

 1.38
Volume Resistivity 4.0X1012 Ohm-meter ASTM D257

170mils / 4.318 mm

1.43

180mils / 4.572 mm

 1.50
Fire rating 94 V0

equivalent UL

190mils / 4.826 mm

 1.60

200mils / 5.080 mm

 1.72
Thermal conductivity 5.0 W/m-K ASTM D5470 Visua l/ ASTM D751 ASTM D5470

Standard Thicknesses:

0.020" (0.51mm) 0.030" (0.76mm)

0.040" (1.02mm) 0.050" (1.27mm) 0.060" (1.52mm)

0.070" (1.78mm) 0.080" (2.03mm) 0.090" (2.29mm)

0.100" (2.54mm) 0.110" (2.79mm) 0.120" (3.05mm)

0.130" (3.30mm) 0.140" (3.56mm) 0.150" (3.81mm)

0.160" (4.06mm) 0.170" (4.32mm) 0.180" (4.57mm)

0.190" (4.83mm) 0.200" (5.08mm)

Consult the factory to alternate thickness.

Standard Sheets Sizes:

8" x 16"(203mm x 406mm)

TIF™ series Individual die cut shapes can be supplied.
