Silicone Thermal Pad 8.0W With Thickness Of 0.5/1/1.5/2/3mm Heat Resistance High Temperature Resistance For PC
Silicone Thermal Pad 8.0W With Thickness Of 0.5/1/1.5/2/3mm Heat Resistance High Temperature Resistance For PC
Silicone Thermal Pad 8.0W With Thickness Of 0.5/1/1.5/2/3mm Heat Resistance High Temperature Resistance For PC
Silicone Thermal Pad 8.0W With Thickness Of 0.5/1/1.5/2/3mm Heat Resistance High Temperature Resistance For PC
Specifications
Brand Name :
ZIITEK
Model Number :
TIF720HQ Series
Certification :
UL and RoHs
Place of Origin :
China
MOQ :
1000pcs
Price :
negotiation
Supply Ability :
10000/day
Delivery Time :
3-5work days
Packaging Details :
1000pcs/bag
Products name :
Silicone Thermal Pad 8.0W With Thickness Of 0.5/1/1.5/2/3mm Heat Resistance High Temperature Resistance For PC
Construction :
Ceramic filled silicone elastomer
Thermal conductivity& Compostion :
8.0 W/m-K
Specific Gravity :
3.5g/cc
Keywords :
Thermal Conductive Pad
Thickness :
0.5mmT
Color :
Gray
Continuos Use Temp :
-45℃ to 200℃
Hardness :
45±5 Shore 00
Description

Silicone Thermal Pad 8.0W With Thickness Of 0.5/1/1.5/2/3mm Heat Resistance High Temperature Resistance For PC

The TIF720HQ thermal silicone pad is a product with both performance and economy. It is a unique thermal pad with low oil permeability, low thermal resistance, high softness and high compliance.It can work stably at -45℃~200℃ and meet the requirement of UL94V0.


Features:


> Good thermal conductive:8.0W/MK
> Moldability for complex parts
> Soft and compressible for low stress applications
> RoHS compliant
> UL recognized
> Easy release construction


Applications:

> Cooling components to the chassis of frame
> High speed mass storage drives
> Heat Sinking Housing at LED-lit BLU in LCD
> LED TV and LED-lit lamps
> RDRAM memory modules
> Display card
> Mainboard/mother board
> Notebook
> Power supply

Typical Properties of TIF720QE Series
Color Gray Visual
Construction & Compostion Ceramic filled silicone elastomer ******
Specific Gravity 3.5g/cc ASTM D297
thickness 0.5mmT ASTM D374
Hardness (thickness＜1.0mm) 55±5 (Shore 00) ASTM 2240
Hardness (thickness≥ 1.0mm) 45±5 (Shore 00) ASTM 2240
Continuos Use Temp -45 to 200℃ ******
Dielectric Breakdown Voltage >5500 VAC ASTM D149
Dielectric Constant 5.0MHz ASTM D150
Volume Resistivity 1.0X10¹²Ohm-meter ASTM D257
Fire rating 94 V0 equivalent UL
Thermal conductivity 8.0W/m-K ASTM D5470

Standard Thicknesses:

0.020" (0.51mm) 0.030" (0.76mm)

0.040" (1.02mm) 0.050" (1.27mm) 0.060" (1.52mm)

0.070" (1.78mm) 0.080" (2.03mm) 0.090" (2.29mm)

0.100" (2.54mm) 0.110" (2.79mm) 0.120" (3.05mm)

0.130" (3.30mm) 0.140" (3.56mm) 0.150" (3.81mm)

0.160" (4.06mm) 0.170" (4.32mm) 0.180" (4.57mm)

0.190" (4.83mm) 0.200" (5.08mm)

Consult the factory to alternate thickness.


Standard Sheets Sizes:
8" x 16"(203mm x 406mm)
TIF™ series Individual die cut shapes can be supplied.
Silicone Thermal Pad 8.0W With Thickness Of 0.5/1/1.5/2/3mm Heat Resistance High Temperature Resistance For PC

Packaging Details & Lead time

The packaging of thermal pad

1.with PET film or foam-for protection

2. use Paper Card To Separate Each Layer

3. export carton inside and outside

4. meet with customers' requirement-customized

Lead Time :Quantity(Pieces):5000

Est. Time(days): To be negotiated
