Self Adhesive Construction Heat Insulation Foam With Aluminium Foil One Side
Self Adhesive Construction Heat Insulation Foam With Aluminium Foil One Side
Self Adhesive Construction Heat Insulation Foam With Aluminium Foil One Side
Self Adhesive Construction Heat Insulation Foam With Aluminium Foil One Side
Self Adhesive Construction Heat Insulation Foam With Aluminium Foil One Side
Self Adhesive Construction Heat Insulation Foam With Aluminium Foil One Side
Self Adhesive Construction Heat Insulation Foam With Aluminium Foil One Side
Self Adhesive Construction Heat Insulation Foam With Aluminium Foil One Side
Self Adhesive Construction Heat Insulation Foam With Aluminium Foil One Side
Self Adhesive Construction Heat Insulation Foam With Aluminium Foil One Side
Self Adhesive Construction Heat Insulation Foam With Aluminium Foil One Side
Self Adhesive Construction Heat Insulation Foam With Aluminium Foil One Side
Specifications
Place of Origin :
Guangdong, China (Mainland)
Brand Name :
CTF
Model Number :
Construction Heat Insulation Foam
Supply Ability :
500 tons per month
Packaging Details :
pe bags or customized
MOQ :
10000 Meter/Meters
Price :
$1.21 - $1.29 / Meters
Certification :
CE ISO SGS REACH ROSH
Delivery Time :
10-15days
Type :
Other Heat Insulation Materials
Port :
Shenzhen
Material :
LDPE
Density :
28-350kg/m3
Thickness :
3-60mm
Description

Self adhesive PE foam with aluminium foil one side

1. Excellent performance, surface resistivity and volume resistivity is very stable, at the same time, according to the customer requirement between adjusted
2. With anti-static properties in not affect by environment or dry humidity
3. Environmental protection, non-toxic, no odor
4. Shockproof
5. Good performance: Cutting, adhesive processed into customer requirements of various shapes 25 IXPE Technical parameters of 40kg/m3 conductivity IXPE foam
6. High temperature resistance: IXPE resists a maximum temperature of 80°C.
7. Heat insulation, sound insulation, abrasion resistance; hard to lose and consume.
8. Nonchemical corrosion: free chemical corrosion to the electronic devices and the packing materials.
9. Superior buffering and cushioning performance: independent and meticulous closed cell
Products features

PE foam+pure aluminium foil (coated aluminum foil)

Reflecting up to 97% of radiant heat

Excellent fire properties

Excellent acoustic insulating properties

Environmentally/Eco friendly and fibre-free

Product Description

Foam Dimension-the thickness ,width and length ,they all can be customize.

Customization Aluminum ,PE foam can laminated with pure aluminum foil or coated aluminum foil etc

Normal thickness

one foaming1-10mm, 100mm after lamination

Normal width

1000mm,1200mm,1300mm,1500mm

Normal length

50m,100m,150m,200m

Product Testing

Density 200±30 125±15 100±10 66.7±8 50±6 40±4 33.3±3
Hardness 60-70 50-60 45-50 35-45 30-35 2-30 18-25

Water absorption

(23°C 24h)g/cm³

 ≤0.02 ≤0.02 ≤0.03 ≤0.03 ≤0.04 ≤0.04 ≤0.05
Thermal conductivity ≤0.092 ≤0.082 ≤0.07 ≤0.062 ≤0.053 ≤0.047 ≤0.041
Tensile strength(mpa) L ≥1.35 ≥1.12 ≥0.88 ≥0.68 ≥0.39 ≥0.33 ≥0.25
M ≥1.08 ≥0.89 ≥0.71 ≥0.56 ≥0.33 ≥0.25 ≥0.20
Elongation L ≥170 ≥150 ≥130 ≥120 ≥100 ≥90 ≥80
M ≥190 ≥170 ≥150 ≥140 ≥110 ≥100 ≥90
Tearing strength L ≥5.90 ≥4.80 ≥3.60 ≥2.80 ≥1.80 ≥1.60 ≥1.35
M ≥7.10 ≥5.40 ≥4.00 ≥3.30 ≥2.30 ≥2.00 ≥1.70


Product Application

Widely used In the fields of Insulation, Sealing and Cushioning, we supply PE foam products in roll, tape, sheet available in areas of

Thermal absorption

Sound absorption

Flame retardant

Product Packaging & Delivery

Foam status

tubes,sheets and blocks,rolls

Packaging Details

packing as request or common packing with PE bag.

Delivery Details

10-15 Work Days

Our Services

CYG TEFA offers the best solution for polyethylene foam production based on long experience in the developing ,manufacturing PE foam.All the service are focused on quality of products and satisfied our customer.

CYG TEFA stocks many different types of foam with the following special properties:

Adhesive

Anti-Microbial

Anti-Static (A/S)

Conductive

Electrostatic Dissipative (ESD)

Fire Retardant (FR)

FAQ

What is PE foam?


A: Polyethylene foam is a strong, resilient closed-cell foam. Ideally foam material suited as the material or part of a material required in products requiring a shock absorbing, vibration dampening, insulation, barrier or buoyancy component etc.

Why choose Low-density polyethylene foam?

A:Low-density polyethylene foam has numerous applications because of its many desirable properties including water-resistance, chemical resistance, energy-absorbance, buoyancy and cushioning characteristics. Compressive strength is greater in denser foams, decreasing as density decreases. Low-density foams tend to exhibit more compressive creep, meaning they become less thick over time, than higher-density foams.

How can I know the suitable foam density I need?

A:Our PE foam density is between 25 kg/m3 and 240 kg/m3

We can provide the best solution for you according the application,Density,hardness,thickness.And The free sample is available for your confirm and text

How can I pay you?


A: After you confirm our PI, we will request you to pay. T/T (ABC bank) and Paypal, Western Union are the most usual ways we are using for freight fees of PE foam samples.
