Embedded Panel Mount Printers , portable small thermal printer for cash register
Embedded Panel Mount Printers , portable small thermal printer for cash register
Embedded Panel Mount Printers , portable small thermal printer for cash register
Embedded Panel Mount Printers , portable small thermal printer for cash register
Embedded Panel Mount Printers , portable small thermal printer for cash register
Embedded Panel Mount Printers , portable small thermal printer for cash register
Embedded Panel Mount Printers , portable small thermal printer for cash register
Embedded Panel Mount Printers , portable small thermal printer for cash register
Specifications
Brand Name :
MASUNG
Model Number :
MS-SP701(a)
Certification :
CE; ROSH
Place of Origin :
China
MOQ :
1
Price :
USD1~30/piece
Payment Terms :
T/T/Western union
Supply Ability :
5,000 units/monthly
Delivery Time :
5~8 days
Packaging Details :
carton
Printing method :
Thermal dot line
Dot numbers(dots/line) :
384 dots/line
Resolution (dots/mm) :
8 dot/mm
Printing speed(mm/s)max :
80
Paper width(mm) :
58
Printing width(mm) :
48
Roll diameter max :
Φ50mm
Paper thickness :
60～80 μm
Paper loading method :
Easy loading
Printer head :
thermistor
System :
Windows/Linux/Android
Description

Embedded Panel Mount Printers , portable small thermal printer for cash register

Quick Detail:

► Compatible with APS printer EMP207

► Front panel mounted structure

► Ultra big paper bucket

► Wide work voltage DC 5 ~8.5 V

► Easy paper loading

► Simple tear bar design

► Interface diversification

►Complete embedded printing solution for faster integration

Description:

MS-SP701 is one kind 58mm thermal panel printer integrated with big paper bucket.

Specification:

Model

MS-SP701

Mechanism

Printing method

Thermal dot line

Dot numbers(dots/line)

384 dots/line

Resolution (dots/mm)

8 dot/mm

Printing speed(mm/s)max

80

Paper width(mm)

58

Printing width(mm)

48

Roll diameter max

Φ50mm

Paper thickness

60～80 μm

Paper loading method

Easy loading

Auto cutting

No

sensor

Printer head

thermistor

Paper end

Photo interrupter

Power feature

Working voltage(Vp)

5V~8.5V

Power consumption

2.8A(average)

Peak current

4.64A

Environment

Working temperature

0～50℃

Working humidity

10～90%RH

Storage temperature

-20～60℃

Storage humidity

5～95%RH

Reliability

Pulse

100,000,000

Printing length(km)

Over 100

Property

Dimension

76.6×73.6×54.8mm

Weight

82±15g

Support

Interface

RS-232/TTL/USB

Commands

ESC/POS

Driver

Windows/Linux/Android

Application:

Cash register; handheld terminals; measuring instruments and analyzers; mobile printers; weighing scales; medical devices; vehicle mounted recorder and more

Competitive Advantage:

  1. Short lead time
  2. Brand-name printer parts
  3. Small order accepted
  4. Product performance
  5. Customization offer
  6. Prompt delivery
  7. Customized service
  8. Professional tech support
  9. Embedded Panel Mount Printers , portable small thermal printer for cash register

Thank you for your visit, any questions or needs, please feel free to contact us, we will serve you wholeheartedly!!
