12V ~ 24V Thermal Printer Mechanism Long Standby Time For Linux / Android / Windows
12V ~ 24V Thermal Printer Mechanism Long Standby Time For Linux / Android / Windows
12V ~ 24V Thermal Printer Mechanism Long Standby Time For Linux / Android / Windows
12V ~ 24V Thermal Printer Mechanism Long Standby Time For Linux / Android / Windows
12V ~ 24V Thermal Printer Mechanism Long Standby Time For Linux / Android / Windows
12V ~ 24V Thermal Printer Mechanism Long Standby Time For Linux / Android / Windows
12V ~ 24V Thermal Printer Mechanism Long Standby Time For Linux / Android / Windows
12V ~ 24V Thermal Printer Mechanism Long Standby Time For Linux / Android / Windows
Specifications
Brand Name :
MASUNG
Model Number :
MS-N58V
Certification :
CE/ROHS
Place of Origin :
CHINA
MOQ :
1
Price :
negotiable
Payment Terms :
T/T
Supply Ability :
2000 set per month
Packaging Details :
carton and foam materials
Model number :
MS-N58V
Printing method :
Thermal dot line printing
Dot pitch :
0.125mm
dots :
384 dots
Print width :
48mm
Paper width :
58mm
Maximum print speed（mm/s）max :
80mm
Color :
Black
Description

58mm 12V ~ 24V Thermal Dot Line Printer Mechanism Linux/Android/Windows support

Summary

The specification Manual is used for the MS-N58V print module. This manual adapt to the voltage range between 12V to 24V, GB18030 Simplified Chinese(24*24dots),If there are any requirements, please consult us in advance.

Features

Portable type

►panel mount structure

►Long standby time

►logo printing

►Paper jam prevention

►Linux/Android/Windows support

specification:

items Specifications

Print

 Printing method Thermal dot line printing
Total dots per line(dot/lines) 384dots
Printable dots per line(dot/lines) 384dots
Dot pitch 0.125mm(8dots/mm)
Maximum print speed(mm/s)max 80
Print width(mm) 48
Paper width(mm) 58mm
Paper feeding method Slide feeding
Type of paper cutting Full cut and Partial cut (1.5±0.5mm tab left at the center)
Detection Thermal head temperature detection Thermistor
Platen position detection mechanical switch
Out-of-paper detection Reflection type photo interrupter
Condition Operating voltage range(Vp) 12~24V
Current consumption Approximately 0.87A
Autocutter current consumption 1.0 A max
Temperature Operating temperature 0—50°C(Non condensing)
Storage temperature -20—60°C(Non condensing)
Life span Activation pulse resistance 100 million pulses or more
Abrasion resistance(km) 50km or more
Appearance Dimensions(including mounting part) W98mm*D81mm*H60mm
Mass Approximately 230g

12V ~ 24V Thermal Printer Mechanism Long Standby Time For Linux / Android / Windows

Thank you for your coming. Please feel free to contact us if you have any questions or needs. We will serve you sincerely!
