Specifications
Brand Name :
MASUNG
Model Number :
MS-D347-V
Certification :
CE/RoHs
Place of Origin :
China
MOQ :
1
Price :
1-200USD/Pieces
Payment Terms :
T/T
Supply Ability :
5000
Delivery Time :
5-15days
Packaging Details :
Cartons/foam material
mechanism :
CAPD347
Dots/line :
576 dots/line
Printing speed :
200 mm/s
Paper loading :
Auto loading
Paper end :
Photo interrupter
Work temperature :
-10 ℃~50℃
Paper thickness :
54~91 um
paper width :
80 mm
Printing width :
72 mm
Dimension (L*W*H) :
186.9*121.5*112.2 mm
Weight :
Approx 1.92 kg
Interface :
RS-232 +USB/Parallel
Driver :
Parallel/USB driver
Description

Vertical type 3 Inch Thermal Printer kiosk ticket machine for BANK

Features

  1. Paper thickness:54-91um
  2. Paper press shaft: mechanism switch
  3. Paper end: photo interrupter
  4. Auto cutting (full/partial)
  5. Ultra high speed reaches at 170mm/s
  6. Easy paper loading
  7. Bezel LED indication
  8. Multiple sensors detection
  9. super big paper holding unit
  10. ticket presenting and retracting function

Specification:

mechanism:

CAPD347

Printing method

Thermal dot line

Dots/line

576 dots/line

Dot pitch

8 dot/mm

Paper width

80 mm

Printing width

72 mm

Paper thickness

54~91 um

Printing speed

200 mm/s

Paper loading

Auto loading

Sensors

Head temperature

Thermistor

Paper press shaft

Mechanical switch

Paper end

Photo interrupter

Paper loading

Easy loading

Font size

ASCII:9*17;12*24;

Chinese: 24*24

Dimension (L*W*H)

186.9*121.5*112.2 mm

Weight

Approx 1.92 kg

Reliability

Cutter: over 7,000,000 cuts

Thermal head: over 100 km

Ambient environment

Work temperature

-10 ℃~50℃

Work humidity

20~85% RH

Storage temperature

-25℃~70℃

Storage humidity

10~90% RH

Interface

RS-232 +USB/Parallel

power supply

DC 24V/3A

Command set

ESC/POS

Barcode

supported

Driver

Parallel/USB driver

System

WindowsXP/Win7(32bits or 64 bits)/

Win8/Android/Linux OS

Accessories:

Sensors

Paper holding unit

Roll spindle

Paper bezel (with LED)

Presenter unit

Interface connector

Power supply unit

Cable

Printer series:

  • Panel mount type: MS-D347
  • Small roll holder type: MS-D347-BE
  • Big roll holder type: MS-D347-TL/TH/V
  • With presenter unit type: MS-D347-TLP/THP

Application:

Self-service terminal; ATM; CDM; parking system; payment kiosk; coupon machine; automatic call distributor;

ticket vendor; inquiry machine; multimedia displayer, gas pumps station and more

Competitive advantages:

  1. Supported paper jam and dragged detection
  2. Compatible with seiko printer mechanism CAPD347
  3. We appreciate small order
  4. Competitive price and smart appearance
