High temperature Capillary Thermostat Temperature Controller

Application:

mainly used for household appliances (shower, drum type washing machines, heaters), heating equipment (stainless steel automatic water boilers, electric frying pans, food machinery, medical equipment), refrigeration industry (kitchen refrigerator, storage cabinets, refrigerator , ice machines, fish ponds, coolers, heaters) and other temperature control purposes.

Detailed Specifications:

This item can be used by Any Electrical Device Which Need Temperature Control

Material: Plastic, Resion, Metal

Action Type: Normal Close

Control Temerature: 30-110 celsius

Power: AC 250V 16A

Frequency: 50/ 60Hz

Connect Method: Two pin connect to power electro circuit

Contact Stick Length:72mm/2.2”

Stick Diameter: 5mm / 0.19"

Description

Changsheng WY-I series bulb & capillary thermostats are factory calibrated to a predetermined temperature range. This design offers a changeover thermal switch and an optional auxiliary switch that is useful for activation of an alarm or cooling fan. The principles of operation allow this design to be surprisingly cost effective and a leading choice for use in many applications where precision sensing is required while remaining on a tight budget. When temperature rises, the internal fluid located within the bulb expands through a capillary tube to an expandable diaphragm that is configured within the remote thermostat body. This diaphragm assembly activates the electrical contacts at the calibrated temperature set point. The WY-I series is available with a front auxiliary switch as optional.

Applications:

■-10 / +16 Refrigeration
■-35 / +35 Fridge
■0 / 40 Ambient
■0 / 85 Boliers / Water heaters
■0 / 93 Dishwashers
■30 / 110 Bain Marie
■60 / 200 Deep-fryer
■50 / 250 Oven
■50 / 300 Oven
■Other ranges upon request
