YS11 BR-B6D Series AC Thermal Protector Thermostat Thermal Switch Epoxy Resin Seal
YS11 BR-B6D Series AC Thermal Protector Thermostat Thermal Switch Epoxy Resin Seal
Specifications
Brand Name :
DESHENG
Model Number :
BR-B6D
Certification :
UL VDE CE CQC
Place of Origin :
China
MOQ :
1000pcs
Payment Terms :
T/T L/C D/P
Supply Ability :
3,000,000pcs/month
Delivery Time :
3-10 days on order date
Packaging Details :
5000pcs per package
Product Name :
AC Thermal Protector
Contact capacity :
125Vac/8A, 250Vac/5A, 24Vdc/8A
Cycles life :
20,000 cycles
Seal :
Epoxy resin
Temperature Tolerance :
±5°C
Certifications :
UL,VDE,CE CQC
Description

250V / 7A, 125V 10A AC Thermal Protector / Motor Circuit Protector BR-B6D For Coils


Applications:

  • Small motors
  • Coils
  • Transformers
  • Washers and dryers
  • Dishwashers
  • Automotive accessory motors
  • Ballast
  • Battery charges
  • ………and more.

YS11 BR-B6D Series AC Thermal Protector Thermostat Thermal Switch Epoxy Resin Seal

Description:

1.High current capacity (125V10A, 250V/7A) to cutout circuit
2.Plastic Case featured small protector.
3.Reliable long service life 20,000cycles.

4.Plastic Case featured small protector.

5. Bimetal discs Carry current, so it is heating & current both sensitive
6. Chattering free and precise operating temperature

7. BR-B6D is constructed with simple design AND it has enough sealing capability to withstand varnish process and reinforced case enabled to be laced on winding.


Specifications:

Contact capacity

125Vac/10A, 250Vac/7A, 24Vdc/8A

Cycles life

10,000 cycles

Open temperature

50°C to 150°C in increments of 5°C

Temperature Tolerance

±5°C

Differential Temperature

depending on open temperature

Seal

Epoxy resin

Contact resistance

≤50 m Ω

Insulation resistance

The resistance between the leads and insulation sleeve is >100 M Ωwith 500 VDC at 25 °C.

Lead wire pull strength

30 N applied from lead to lead for 5sec. No slip-off or rupture


Competitive Advantage:

1. The strongest Chinese manufacturer, ISO 9001and ISO14001 recognized.

2. Compact, miniature size.

3. UL,VDE,CE CQC Approved.

4. Individually temperature checked on modern, custom-designed equipments

5. Snap–action disc, normally on.

6. Epoxy resin

7. Bimetal discs carry circuit current, so it is current and temperature double sensitivity for maximum design flexibility and application


L=15mm W=7.3mm H=3.9mm

YS11 BR-B6D Series AC Thermal Protector Thermostat Thermal Switch Epoxy Resin Seal

Part Description Material

①Lead wire ②Epoxy resin ③PBT Plastic case ④Stationary subassembly ⑤Fixed plate
⑥Bimetal disc ⑦Movable arm ⑧Movable contact ⑨Stationary contact
