Integrated Structure Vacuum Tube Solar Water Heater 300 Liter Aluminium Frame
Integrated Structure Vacuum Tube Solar Water Heater 300 Liter Aluminium Frame
Integrated Structure Vacuum Tube Solar Water Heater 300 Liter Aluminium Frame
Integrated Structure Vacuum Tube Solar Water Heater 300 Liter Aluminium Frame
Integrated Structure Vacuum Tube Solar Water Heater 300 Liter Aluminium Frame
Integrated Structure Vacuum Tube Solar Water Heater 300 Liter Aluminium Frame
Specifications
Brand Name :
PASSION/OEM
Model Number :
300L
Certification :
CE
Place of Origin :
CHINA
MOQ :
1
Price :
Negotiable
Payment Terms :
L/C, T/T, D/P
Supply Ability :
5000units/month
Delivery Time :
10 working days
Packaging Details :
CARTONS/PLYWOOD CASE/PALLET
Capacity :
300L
Structure :
Integrated
Type :
Non Pressurized
Tube :
Vacuum Tube
Hail Resistance :
25mm
Outer Tank :
Stainless Steel 304 – BA
Inner Tank :
Stainless Steel 316L
Frame :
Aluminium Frame
Description

300L Integrated High Efficiency Non Pressurized Vacuum Tube Solar Water Heater Aluminium Frame

Description:

This is an open-loop thermosyphon solar water heater.

Water circulates directly through the tank and the collector, so this is direct and quick.

This system is very stable and reliable performance.

And it’s the most economical and easy system among all solar water heating systems.

So it’s most popularly used in the hot areas.

The details of material:


Evacuated tube: High quality borosilicate glass 3.3, Φ47×1500, Φ58×1800, Φ70×2100
Inner tank: SUS304-2B stainless steel plate
Outer tank: SUS304-2B stainless steel plate
Insulating layer: Polyurethane foam
Bracket: Galvanized steel plate
Capacity of tank: 75L 100L 125L 150L 200L 225L 250L 300L,400L,500L

Feature:


◆ Highly efficient absorber of high performance with daily average efficiency over 50%.
◆ Start up quickly, heat pipe transfer the heat energy into the storage tank in one direction.
◆ Withstand pressure of 6 bar, can be connected directly with city water.
◆ No water inside the evacuated tubes, the solar water heater can still in service even with several tubes breakage.
◆ Highly efficient insulation with polyurethane foam.
◆ Simple structure,easy to assembly and install.
◆ Can be used all year round in the cold climate.
◆ Can be used together with auxiliary electric boost.
◆ Long service life, can be used over 15 years.

SS470/-58/1800-12 to 30 tubes
Water tank Inner tank SUS304-2B (0.5mm)
Outer tank SUS304-2B (0.4mm) or galvanized steel (0.4mm)
Insulation Polyurethane foam (55mm)
Flow type Thermosyphon
Tube Tube size 58/1800mm, 47/1500mm
Evacuated tube High boron-silicon
Absorber Coating Aluminum,stainless steel,copper
Frame Frame material SUS201(1.2mm) or Aluminum(3.0mm) or galvanized steel(1.5mm)
Maximum operation pressure 0.6

Product Model Tubes Capacity Absorbing Area Weight Dimension
(L×W×H)		 Qty. per
20FT/40FT/40HQ
470-1800/58-12 12pcs 120L 0.92m2 52KGS 1770*1050*1560 54 / 108 / 132
470-1800/58-15 15pcs 150L 1.15m2 62KGS 1770*1290*1560 45 / 89 / 108
470-1800/58-18 18pcs 180L 1.37m2 72KGS 1770*1530*1560 38 / 77 / 93
470-1800/58-20 20pcs 200L 1.52m2 80KGS 1770*1690*1560 35 / 70 / 85
470-1800/58-24 24pcs 240L 1.83m2 95KGS 1770*2010*1560 30 / 60 / 73
470-1800/58-30 30pcs 300L 2.29m2 112KGS 1770*2490*1560 24 / 49 / 59

Optional Accessories:

Assistant tank (5L/8L/12L)

Intelligent controller

Electric backup Heating element

Payment Terms L/C, T/T
Minimum Order 2 sets
Lead Time / Delivery Time 15 Day(s)
Sample Available YES
Delivery Details after receipt of payment
Port of Lading Ningbo / Shanghai
Shipping by sea
Packing export carton
Target Market(s) Africa(except Middle East), Central & Southern Asia, Latin America, Southeast Asia
