High Performance Split Solar Water Heater Flat Plate Blue Titanium Coating
High Performance Split Solar Water Heater Flat Plate Blue Titanium Coating
High Performance Split Solar Water Heater Flat Plate Blue Titanium Coating
High Performance Split Solar Water Heater Flat Plate Blue Titanium Coating
Specifications
Brand Name :
PASSION/OEM
Model Number :
200L
Certification :
CE
Place of Origin :
CHINA
MOQ :
1
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
5000units/month
Delivery Time :
10 working days
Packaging Details :
CARTONS/PLYWOOD CASE/PALLET
Capacity :
200L
Coating :
Blue Titanium
Collector :
Flat Plate
Structure :
Split
Outer Tank :
Stainless Steel 304 – BA
Inner Tank :
Stainless Steel
Bracket :
Anodised Aluminium Alloy
Using :
Bathing
Description

200L High Performance Blue Titanium Flat Plate Split Solar Water Heater Anodised Aluminium Alloy for Bathing

Description

The split systems provide an effective way to get hot water from the sun.

Equipped with high-efficiency collectors, intelligent system controller or working station, and pressurized water tanks.

The split systems are always smart choices for harvesting hot water from the sun and saving our heating cost.

Features

1. System capacity available: 150L/200L /250L/300L/400L.

2. Equipped with pressurized water storage tanks (cylinders) with elegant and safe design.
3. Water tank inner is made of SUS304 high grade stainless steel.
4. Open loop or closed loop (anti-freeze) systems available for different climates and water quality.
5. Strong mounting support.

6. Easy installation and maintenance.
7. Full automatic temperature differential control system.
8. Automatic start / stop auxiliary electric heater under preset timing and temperature level.
9. With electric heater in water tank, ensure adequate hot water supplying at cloudy or rainy days.

OPEN LOOP DIRECT SYSTEM SPECIFICATION

Model PT-150 PT-200 PT-250 PT-300 PT-400
System Capacity 150 L 200 L 250 L 300 L 400 L
Water Tank Size 470x1545 520 x 1545 560 x 1625 560 x1925 700 x1625
Number of Collector 1 x 2M2 2 x 1.5M2 2 x 2M2 2 x 2M2 3 x 2M2
Collector Area 2M2 3 M2 4 M2 4 M2 6 M2
Auxiliary Heater 1.5KW 1.5KW 2KW 3KW 3KW
System Controller TK-SC6/ Intelligent, full automatic controller
Circulation Pump* Standard: WILO RS15/6 Screen pump / (Silent operation)
Installation accessories pack 1 set of mounting support (flat roof or pitched roof)
1 set of collector pipe fittings1 x system controller
1 x circulation pump (WILO RS15/6)
1x P/T safety valve 2 x check valves 1x auto air vent

Closed loop (Anti-freeze) Systems

Model PS-150 PS-200 PS-250 PS-300 PS-400
System Capacity 150 L 200 L 250 L 300 L 400 L
Water Tank Size 470x1545 520 x 1545 560 x 1625 560 x1925 700 x1625
Number of Collector 1 x 2M2 2 x 1.5M2 2 x 2M2 2 x 2M2 3 x 2M2
Collector Area 2M2 3 M2 4 M2 4 M2 6 M2
Auxiliary Heater 1.5KW 1.5KW 2KW 3KW 3KW
Heat Exchanger Area
(Copper Coil)		 0.75M2 0.94 M2 1.13 M2 1.32 M2 1.5 M2
Expansion Vessel 5L 5L 8L 8L 12L
Control Station TK-SC8A compact automatic control and working station
Installation accessories pack

1 set of mounting support (flat roof or pitched roof)
1 set of working station (pump + control system)
1 set of collector pipe fittings

1 x expansion vessel 1x P/T safety valve 2 x check valves 1x auto air vent

We have 5 different series of flat plate solar collector, with different design and price level.

Customer can choose a suitable collector model according to local solar irradiance level and system budget is very important.

please view specification sheets of solar collector to determine which model is the most suitable.

Auxiliary Equipment

Insulated pipe and fittings: Supply copper & stainless pipe & fittings with/ without insulation.
Anti-freeze heat carrier: Medical grade heat carrier which is super is anti-freezing and heat transferring.
Installation tools: Including pipe cutter, pipe hammer, carrier filling station

Packing

Evacuated Tube Solar Water Heater: standard export package.

The samples are loaded into the plywood boxes.

Remark

Delivery time: 7-15days

Payment term: sample,100% T/T for the sample

container,30% T/T in advance or L/C

Warranty:6 Years

Trade term: FOB Shanghai, CFR or CIF

Certificates: CE,ISO9001,CCC,SGS
