Heat Pipe 30 Tube Solar Collector , Solar Water Heating Collectors For Apartment
Heat Pipe 30 Tube Solar Collector , Solar Water Heating Collectors For Apartment
Heat Pipe 30 Tube Solar Collector , Solar Water Heating Collectors For Apartment
Heat Pipe 30 Tube Solar Collector , Solar Water Heating Collectors For Apartment
Heat Pipe 30 Tube Solar Collector , Solar Water Heating Collectors For Apartment
Heat Pipe 30 Tube Solar Collector , Solar Water Heating Collectors For Apartment
Specifications
Brand Name :
PASSION/OEM
Model Number :
30tubes
Certification :
CE
Place of Origin :
CHINA
MOQ :
1
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
5000units/month
Delivery Time :
10 working days
Packaging Details :
CARTONS/PLYWOOD CASE/PALLET
Tubes :
30 Tubes
Insulation :
Rock Wool
Mounting :
Aluminum Alloy
Installation :
Inclined Roof
Heat Pipe :
14mm Condenser
Manifold Color :
Silver
Collector :
Heat Pipe
Application :
Apartment
Description

14mm Condenser High Efficiency Heat Pipe Thermal Solar Collector 30 Tubes Rock Wool

Specifications:

This model can withstand high pressure (6 bar ) working, and can meet the demand of large water consumption.

It has anti-freezing function (>-35C), because all the pipelines are made of red copper and conducted by heat transfer medium liquid, no water flows into the tubes when working.

It can still work well even one tube is broken. Also, it is easily installed on the pitched roof or flat roof.

Technical Data

Manifold (interior) : Red copper

Manifold (exterior) : Aluminum alloy

Aluminum fin : 1620mm full length

Heat pipe : Red copper

Insulation Layer : Eco-friendly rockwool 50mm

Vacuum tube : 58*1800mm/SS-CU-ALN coating

Bracket : Aluminum alloy with 27/30/38/45 degree installing angle

Manifold connection (inch) : 3/4

Note : All the systems are available for the customization.

Three-target Vacuum Tube Performance and Specification:
Tube structure All-glass double deck co-axial structure
Glass material High borosilicate 3.3 glass
Outer tube diameter and glass thickness Ø58±0.7mm; Glass thickness 1.6±0.15mm
Inner tube diameter and glass thickness Ø47±0.7mm; Glass thickness 1.6±0.15mm
Tube dimension 58*1800mm
Absorption
coating
property		 Coating material CU/SS-ALN(H)/SS-ALN(L)/ALN
Sediment method Three Target magnetron sputtering plating
Absorptivity α =0.92~0.96 (AM1.5)
Emission ratio Emission: ε=0.04~0.06(80°C±5°C)
Vacuum degree P≤5.0X10-3(PA)

Stagnation temperature

(temperature inside of empty evacuated tubes)

 260~300 °C
Average heat loss ULT 0.4~0.6 W/(m2 *°C)
Hail resistance Ø25 mm
24mm Premium Heat Pipe Performance and Specification:
Heat pipe material Oxygen free copper (TU1),Cu=Ag>99.99%(o2<16ppm)
Condenser dimensions Top: Ø24mm *65mm,Body: Ø8*0.6mm.length:1750± 10mm
Heat-transfer-fins 0.3mm/0.0098’’ thick sets of Aluminum fins,1630mm
Starting speed 30s
Max. operation pressure 6bar
Max. testing pressure 12bar
Stagnation temperature 236°C
Manifold Performance and Specification:
Manifold header pipe TU2 copper
Manifold casing Anodized aluminum alloy (6063-T5/T6)
Insulation layer Compressed rock wool.
Bracket Performance and Specification:
Bracket 2.0mm thickness aluminum alloy bracket.
Vertical installation angle Flat & pitched roof

Optional Accessories

Split Controller

Wilo-Star-Rs 15/6 (Circulation)

Collector Mounting Bracket (Mounting&fixing)

Copper Connector

Flexible Steel Pipe (connection)

Working station

General Order Information:

We take great pride in our work and in the wide variety of products that we offer.

We are experienced in servicing the US market, European market and Africa market .

Please be aware that our production lead times depend on specific items and item quantities. Our success has been based on our understanding of the demands and nature of promotional and marketing deadlines.

That's why we always ensure that every order is delivered on time.

Why choose us ?

we have our clients set to list of reasons why to choose us over other solar water heater,here are our benefits

Engaged in the solar energy application technology for more than 18 years

We has received many honors and passed multiple verification.

The number of service outlets across the country, so you have no worry.

We research and produce all kinds of products , widely used in hospitals, schools, hotels, etc.
