Blue Coating Flat Plate Solar Collector EPDM Insulation Solar Pool Heating Project

Copper Pipe Flat Plate Solar Collectors

The copper Pipe Flat Plate Solar Collectors is a tank of roof-mounted system,

using the thermosiphon principle to transfer heat from collector to water inside tank.

The thermosiphon coating:selective absorb coating and hot water rises.

The collectors are coated with a heat-absorbent surface which absorbs the sun rays and heats the fluid in the collector.

As the fluid heated,it rise the top of the collector panel and into the tank

where it displaces cooler fluid which flows in to the bottom of the collector panel where the process is repeated.

The more temperature difference between the fluid in the collector panel

and water in the tank, the faster flowing and heat exchanging.

Key feature

1. Safe and steady

Flat plate solar collector uses all cooper fluid tube;

System operating is steady; components are not easy to be damaged;

2. Pressurized operating

Working pressure is 0.6Mpa; designed pressure is 1.2Mpa;

the hot water is forced to stream out from the top; it is convenient to use.

3. High heat efficiency

Absorbing coating of the collector is black chrome and blue sputtering;

absorbing rate is 92-96%, and emission rate is 5%-15%; heat efficiency is high.

4. Good temperature preservation

Thickness illustration layer is 50mm; constant temperature high pressure quantitative foam;

less than 5 Celsius Degree per 24.

5. Long using life

Inner tank is 1.2-2.0mm stainless steel; resist high temperature and corrosion; 15 years using life.

6. Several models fulfill different user need

According to customers’ requirement, we put our several modes with different specifications to suit flatlet, villa, hotel and factories. , etc

7. Easy installation

Specifications

1) Special design for Europe market .

2) Special Anodized aluminum alloy frame to ensure handsome appearance

3) Can accept high pressure without leakage50mm fiberglass insulation

4) EPDM seal strip to assure the solar collector can work under harsh and very cold temperature

5) Operation Temperature -33120

6) Patterned temper glass or low iron temper glass (4mm thickness)

7) It is not easy broken with very high transmission and low emission

8) Black chrome or Magnetic blue sputtering coating has very higher absorption rate to ensure the high efficiency.

Packaging & Shipping

Thermosyphon Solar Water Heaters are put into cartons firstly.
The samples are loaded into the plywood boxes.

For the FCL goods, cartons can be loaded into the container directly from solar water heater manufacturer.

Warranty

10 years international responsibility for Flat Plate Panel Solar Collector due to original quality problems.

Notice

1. The angle of the frame can be changed in the production as the virtual geographical condition of the customers.

2. We can design the suitable angle for the customers.

3. We offer the spare accessories and tubes for your order for free.

4. We can offer the different material of water tank , frame , and tubes according to your request.
