Black Thermal Conductive Nylon 5.0W Plastic Material For Cooling For Molding And Plastic Parts
Black Thermal Conductive Nylon 5.0W Plastic Material For Cooling For Molding And Plastic Parts
Black Thermal Conductive Nylon 5.0W Plastic Material For Cooling For Molding And Plastic Parts
Black Thermal Conductive Nylon 5.0W Plastic Material For Cooling For Molding And Plastic Parts
Specifications
Brand Name :
Ziitek
Model Number :
TCP200-50-02A
Certification :
RoHS
Place of Origin :
China
MOQ :
25kg
Price :
USD 10-100/BAG
Payment Terms :
T/T
Supply Ability :
1000bag/month
Delivery Time :
3-7 work days
Packaging Details :
25kg/bag
Products name :
Black Thermal Conductive Nylon 5.0W Plastic Material For Cooling For Molding And Plastic Parts
Color :
black
Specific Gravity :
1.45g/cc
thermal conductivity through plane :
5.0W/mK
Heat Deflection Temperature :
150℃
Keywords :
Thermal Nylon Plastic Material
Material :
Nylon
Description

Black Thermal Conductive Nylon 5.0W Plastic Material For Cooling For Molding And Plastic Parts

TCPTM200-50-02A is a Thermally Conductive EngineeringPlastic developed for the housing design which requires highthermally conductivity and reduces the weight more than 30%comparing with the same aluminium devices.

Application
TCP™100-25-06A can be used in applications such as Heat Sinking Housing at LED-lit BLU in LCD/LED TV and LED-lit lamps such as MR16. Also it can replace the normal Aluminum heat sink.

Black Thermal Conductive Nylon 5.0W Plastic Material For Cooling For Molding And Plastic Parts

Feature
>Good thermal conductivity: 5.0W/mK

>Excellent thermal conductivity compared to normal engineering plastics
>Lighter than normal Aluminum housing 30% in weight
>Excellent mould ability in injection moulding

>Much higher production yield than normal

Typical Properties of TCPTM200-50-02A
Items Test method Unit Typical data
Physical Properties
Material ***** ***** Nylon
Color Visual ***** black
Melt index ASTM D1238 g/10min 4
Specific Gravity ASTM D792 g/cm3 1.45
Shrinkage ASTM D955 % 0.3-0.5
Mechanical Properties
Tensile Strength ASTM D638 MPa 55
Flexural Strength ASTM D790 MPa 80
Flexural Modulus ASTM D638 MPa 15800
Impact Strength, notched ASTM D256 kJ/㎡ 2.5~3.5
Electrical Properties
Dielectric Constant, 1MHz ASTM D150 ***** 4.5
Volume Resistivity ASTM D257 Ohm-meter 10000
Thermal Properties
Heat Deflection Temperature ASTM D648 ℃ 150

Vicat Temperature

 ASTM D648 ℃ 15.0
Thermal Conductivity Throngh Plane ASTM E1461 W/m-K 5.0
Flame retardancy Min. thick. 1.0mm Class V-0

Black Thermal Conductive Nylon 5.0W Plastic Material For Cooling For Molding And Plastic Parts

Company profile

Ziitek Electronic Material and Technology Ltd. is dedicated to developing composite thermal solution and manufacturing superior thermal interface materials for competitive market. Our vast experience allows us to assist our customers best in thermal engineering field.We serve customers with customized products, full product lines and flexible production, which makes us be the best and reliable partner of you. Let's make your design more perfect!

FAQ:

Q: Are you trading company or manufacturer ?

A: We are manufacturer in China.

Q: How long is your delivery time?

A: Generally it is 3-7 work days if the goods are in stock. or it is 7-10 work days if the goods are not in stock, it is according to quantity.

Q: Do you provide samples ? is it free or extra cost?

A: Yes, we could offer samples free of charg.

Q: How do I request customized samples?

A: To request samples, you can leave us message on website, or just contact us by send email or call us.
