Tackiness Thermal Pad Offering Low Stress Applications 0.5mmT TIF120-18-01US
Tackiness Thermal Pad Offering Low Stress Applications 0.5mmT TIF120-18-01US
Tackiness Thermal Pad Offering Low Stress Applications 0.5mmT TIF120-18-01US
Tackiness Thermal Pad Offering Low Stress Applications 0.5mmT TIF120-18-01US
Specifications
Brand Name :
Ziitek
Model Number :
TIF120-18-01US thermal pad
Certification :
UL
Place of Origin :
China
MOQ :
1000 pcs
Price :
0.1-10 USD/PCS
Payment Terms :
T/T
Supply Ability :
100000pcs/month
Delivery Time :
3-8 work days
Packaging Details :
25*24*13cm canton
hardness :
18 shore00
KEYWORD :
black silicone rubber pads
color :
black
part number :
TIF120-18-01US
material :
silicone
Description

Excellent Wet-Out Thermal Pad for High speed mass storage drives,5.0mmT TIF1200-30-11US


Company Profile

Ziitek company is a high-tech enterprise which dedicated to the R&D, manufacture and sales of the thermal interface materials (TIMs). We have rich experiences in this field which can support you the latest, most effective and one -step thermal management solutions. We have many advanced production equipments,full test equipments and fully automatic coating production lines which can support the production for high performance thermal silicone pad, thermal graphite sheet/ film, thermal double-sided tape, thermal insulation pad, thermal ceramic pad, phase change material, thermal grease etc. UL94 V-0, SGS and ROHS are compliant.

TIF100-18-01US-Specification-sheet.pdf

TIF120-18-01US is not only designed to take advantage of the gap heat transfer, to fill gaps, complete the heat transfer between heating and cooling parts, but also played insulation, damping, sealing and so on, to meet the equipment miniaturization and ultra-thin design Requirements, which is a highly technology and use, and the thickness of the wide range of applications, is also an excellent thermal conductivity filler material.
Features
<Good thermal conductive:1.8W/mK
<Thickness:0.5mmT
<Hardness:18 Shore 00
<Colour: black

<Soft and compressible for low stress applications

<Naturally tacky needing no further adhesive coating

<Electrically isolating

<High durability

Applications

<Heat Sinking Housing at LED-lit BLU in LCD

<LED TV and LED-lit lamps

<RDRAM memory modules

<IT infrastructure

<GPS navigation and other portable devices

<CD-Rom, DVD-Rom cooling


Typical Properties of TIF120-18-01US
Product Name

TIF120-18-01US Series
Colour
 black
Construction & Compostion
Ceramic filled silicone elastomer

Specific gravity
2.5 g/cc

Thickness
0.5mmT
Hardness
18 Shore 00
Dielectric constant@1MHz
4.5 MHz
Continuos Use Temp
-40to 160℃
Dielectric Breakdown Voltage
>5500 VAC
Thermal conductivity
1.8 W/mK
Volume Resistiviyt

1.0*1012 Ohm-cm

Peressure Sensitive Adhesive:

Request adhesive on one side with "A1" suffix.

Request adhesive on double side with "A2" suffix.

Reinforcement: TIF™ series sheets type can add with fiberglass reinforced.

Standard Thicknesses:

0.020" (0.51mm) 0.030" (0.76mm)

0.040" (1.02mm) 0.050" (1.27mm) 0.060" (1.52mm)

0.070" (1.78mm) 0.080" (2.03mm) 0.090" (2.29mm)

0.100" (2.54mm) 0.110" (2.79mm) 0.120" (3.05mm)

0.130" (3.30mm) 0.140" (3.56mm) 0.150" (3.81mm)

0.160" (4.06mm) 0.170" (4.32mm) 0.180" (4.57mm)

0.190" (4.83mm) 0.200" (5.08mm)

Consult the factory to alternate thickness.

Tackiness Thermal Pad Offering Low Stress Applications 0.5mmT TIF120-18-01US

FAQ

Q: How long is your delivery time?

A: Generally it is 3-7 work days if the goods are in stock. or it is 7-10 work days if the goods are not in stock, it is according to quantity.

Q: How do I request customized samples?

A: To request samples, you can leave us message on website, or just contact us by send email or call us.
