3.0W/MK Thermal Gap Filler 27shore00 For Heat Sinking Housing At LED-Lit BLU In LCD
3.0W/MK Thermal Gap Filler 27shore00 For Heat Sinking Housing At LED-Lit BLU In LCD
3.0W/MK Thermal Gap Filler 27shore00 For Heat Sinking Housing At LED-Lit BLU In LCD
3.0W/MK Thermal Gap Filler 27shore00 For Heat Sinking Housing At LED-Lit BLU In LCD
3.0W/MK Thermal Gap Filler 27shore00 For Heat Sinking Housing At LED-Lit BLU In LCD
3.0W/MK Thermal Gap Filler 27shore00 For Heat Sinking Housing At LED-Lit BLU In LCD
Specifications
Brand Name :
Ziitek
Model Number :
TIF5120-30-11U thermal pad
Certification :
UL
Place of Origin :
China
MOQ :
1000 pcs
Price :
0.1-10 USD/PCS
Payment Terms :
T/T
Supply Ability :
100000pcs/month
Delivery Time :
3-8 work days
Packaging Details :
25*24*13cm canton
hardness :
27shore00
KEYWORD :
grey silicone rubber pads
color :
grey
part number :
TIF5120-30-11U
material :
silicone
Thickness :
3.0mmT
Description

3.0W/mK professional factory thermal gap filler 27shore00 For Heat Sinking Housing at LED-lit BLU in LCD

Company Profile

With a wide range, good quality, reasonable prices and stylish designs, Ziitek thermal conductive interface materials are extensively used in Mainboards, VGA cards, Notebooks, DDR&DDR2 products, CD-ROM ,LCD TV, PDP products, Server Power products, Down lamps, Spotlights, Street lamps, Daylight lamps, LED Server Power products and others.

TIF500-30-11U Datasheet-REV02.pdf

The TIF5120-30-11U is not only designed to take advantage of the gap heat transfer, to fill gaps, complete the heat transfer between heating and cooling parts, but also played insulation, damping, sealing and so on, to meet the equipment miniaturization and ultra-thin design Requirements, which is a highly technology and use, and the thickness of the wide range of applications, is also an excellent thermal conductivity filler material.
Features
<Broad range of hardnesses available 3.0W/mK
<Thickness:3.0mmT

<Outstanding thermal performance

<Fiberglass reinforced for puncture, shear and tear resistance

<Electrically isolating

Applications

<Heat Sinking Housing at LED-lit BLU in LCD

<LED TV and LED-lit lamps

<Micro heat pipe thermal solutions

<Automotive engine control units

<Memory Modules

<Mass storage devices


Typical Properties of TIF 5120-30-11U
Product Name
TIF5120-30-11U Series
Colour
Grey
Construction & Compostion
Ceramic filled silicone rubber
Specific Gravity
3.0g/cc
Dielectric Constant@1MHz
4.4 MHz
Hardness
27Shore 00
Flame Rating
94 -V0
Continuos Use Temp
-40to 160℃
Dielectric Breakdown Voltage
>5500 VAC
Thermal conductivity
3.0 W/mK
Thickness
 3.0mmT

Packaging Details & Lead time

The packaging of thermal pad

1.with PET film or foam-for protection

2. use Paper Card To Separate Each Layer

3. export carton inside and outside

4. meet with customers' requirement-customized

Lead Time :Quantity(Pieces):5000

Est. Time(days): To be negotiated

Standard Sheets Sizes:

8" x 16"(203mm x 406mm)

TIF™ series Individual die cut shapes can be supplied.
