5.0mmT Electrically Isolating Silicone Sheets 20shore00 For Micro Heat Pipe Solutions
5.0mmT Electrically Isolating Silicone Sheets 20shore00 For Micro Heat Pipe Solutions
5.0mmT Electrically Isolating Silicone Sheets 20shore00 For Micro Heat Pipe Solutions
5.0mmT Electrically Isolating Silicone Sheets 20shore00 For Micro Heat Pipe Solutions
5.0mmT Electrically Isolating Silicone Sheets 20shore00 For Micro Heat Pipe Solutions
5.0mmT Electrically Isolating Silicone Sheets 20shore00 For Micro Heat Pipe Solutions
Specifications
Brand Name :
Ziitek
Model Number :
TIF5200-50-11US thermal pad
Certification :
UL
Place of Origin :
China
MOQ :
1000 pcs
Price :
0.1-10 USD/PCS
Payment Terms :
T/T
Supply Ability :
100000pcs/month
Delivery Time :
3-8 work days
Packaging Details :
25*24*13cm canton
hardness :
20shore00
KEYWORD :
grey silicone rubber pads
color :
grey
part number :
TIF5200-50-11US
material :
silicone
thermal conductive :
5.0W/m-k
Description

5.0mmT Electrically isolating silicone sheets ,ultra soft 20shore00 For Micro heat pipe thermal solutions


Ziitek TIF5200-50-11US is a highly compliant Gap Pad material that is ideal for fragile component leads. The material is fiberglass reinforced for improved puncture resistance and handling TIF5200-50-11US maintains a conformable, yet elastic nature that provides excellent interfacing and wet-out characteristics, even to surfaces with high roughness or uneven topography. TIF5200-50-11US features an inherent tack on both sides of the material, eliminating the need for thermally impeding adhesive layers.Options and ConfigurationsStandard sheet size - 8" x 16" or custom configurationStandard thickness available - 0.020", 0.040", 0.060", 0.080", 0.100", 0.125", 0.160", 0.200", 0.250"Custom made configurations available upon request

TIF500-50-11US Datasheet-REV02.pdf

Company Profile
With a wide range, good quality, reasonable prices and stylish designs, Ziitek thermal conductive interface materials are extensively used in Mainboards, VGA cards, Notebooks, DDR&DDR2 products, CD-ROM ,LCD TV, PDP products, Server Power products, Down lamps, Spotlights, Street lamps, Daylight lamps, LED Server Power products and others.

Features

<Good thermal conductive:5.0W/m-k
<Thickness:5.0mmT
<Moldability for complex parts
<Naturally tacky needing no further adhesive coating
<Broad range of hardnesses available

Applications

<High speed mass storage drives
<Telecommunication hardware
<Handheld portable electronics
<Set top boxes
<Audio and video components

Typical Properties of TIF 5200-50-11US
Product Name
TIF5200-50-11US Series
Colour
Grey
Construction & Compostion
Ceramic filled silicone rubber
Specific Gravity
3.0g/cc
Dielectric Constant@1MHz
4.0 MHz
Hardness
20 Shore 00
Flame Rating
94 -V0
Continuos Use Temp
-40to 160℃
Dielectric Breakdown Voltage
>5500 VAC
Thermal conductivity
5.0 W/mK
Thickness
 5.0mmT

Standard Thicknesses:

0.020" (0.51mm) 0.030" (0.76mm)
0.040" (1.02mm) 0.050" (1.27mm) 0.060" (1.52mm)
0.070" (1.78mm) 0.080" (2.03mm) 0.090" (2.29mm)
0.100" (2.54mm) 0.110" (2.79mm) 0.120" (3.05mm)
0.130" (3.30mm) 0.140" (3.56mm) 0.150" (3.81mm)
0.160" (4.06mm) 0.170" (4.32mm) 0.180" (4.57mm)
0.190" (4.83mm) 0.200" (5.08mm)

Consult the factory to alternate thickness.

Peressure Sensitive Adhesive:
Request adhesive on one side with "A1" suffix.
Request adhesive on double side with "A2" suffix.

Reinforcement: TIF™ series sheets type can add with fiberglass reinforced.

5.0mmT Electrically Isolating Silicone Sheets 20shore00 For Micro Heat Pipe Solutions

FACTORY INFORMATION:

Factory Size
5,000-10,000 square meters

Factory Country/Region
Building B8, Industry District Ⅱ, Xicheng, Hengli Township, Dongguan City, Guangdong Province, P.R.China

Annual Output Value
US$1 Million - US$2.5 Million

Certifications:

ISO9001:2015

ISO14001: 2004 IATF16949:2016

IECQ QC 080000:2017

UL
