Easy Release Construction Grey Silicone Pads For LED Power Supply
Easy Release Construction Grey Silicone Pads For LED Power Supply
Easy Release Construction Grey Silicone Pads For LED Power Supply
Easy Release Construction Grey Silicone Pads For LED Power Supply
Specifications
Brand Name :
Ziitek
Model Number :
TIF7140M thermal pad
Certification :
UL
Place of Origin :
China
MOQ :
1000 pcs
Price :
0.1-10 USD/PCS
Payment Terms :
T/T
Supply Ability :
100000pcs/month
Delivery Time :
3-8 work days
Packaging Details :
25*24*13cm canton
Continuos Use Temp :
-40 to 160℃
Name :
Easy release construction Grey silicone pads for LED Power Supply
Hardness :
50 Shore 00
Flame Rating :
94-V0
keyword :
Thermal Gap Pad
Dielectric Breakdown Voltage :
>5500 VAC
Description

Easy release construction Grey silicone pads for LED Power Supply

Company Profile

Ziitek Electronic Material and Technology Ltd. is dedicated to developing composite thermal solution and manufacturing superior thermal interface materials for competitive market.

Our vast experience allows us to assist our customers best in thermal engineering field.

We serve customers with customized products, full product lines and flexible production, which makes us be the best and reliable partner of you. Let's make your design more perfect!

TIF700M-Series-Datasheet.pdf

Ziitek TIF7140M use a special process, with silicone as the base material, adding thermal conductive powder and flame retardant together to make the mixture to become thermal interface material. This is effective in lower the thermal resistance between the heat source and the heat sink.


<Good thermal conductive: 6.0 W/mK
<Thickness: 3.5mmT
<Hardness:50 Shore 00
<Colour: Grey

<RoHS compliant
<UL recognized
<Easy release construction


Applications

<LED Power Supply

<LED Controller

<LED Ceilinglamp

<Monitoring the Power Box

<AD-DC Power Adapters

<Rainproof LED Power

Typical Properties of TIF7140M
Product Name TIF7140MSeries
Colour Grey
Construction & Compostion Ceramic filled silicone elastomer
Specific gravity

3.25 g/cc
Thickness 3.5mmT
Hardness 50 Shore 00
Dielectric constant@1MHz 4.2 MHz
Continuos Use Temp -40 to 160℃
Dielectric Breakdown Voltage >5500 VAC
Thermal conductivity 6.0W/mK
Flame Rating 94-V0


Standard Thicknesses:

0.020" (0.51mm) 0.030" (0.76mm)

0.040" (1.02mm) 0.050" (1.27mm) 0.060" (1.52mm)

0.070" (1.78mm) 0.080" (2.03mm) 0.090" (2.29mm)

0.100" (2.54mm) 0.110" (2.79mm) 0.120" (3.05mm)

0.130" (3.30mm) 0.140" (3.56mm) 0.150" (3.81mm)

0.160" (4.06mm) 0.170" (4.32mm) 0.180" (4.57mm)

0.190" (4.83mm) 0.200" (5.08mm)

Consult the factory to alternate thickness.

Easy Release Construction Grey Silicone Pads For LED Power Supply



Ziitek Culture

Quality :

Do it right the first time, total quality control

Effectiveness:

Work precisely and thoroughly for effectiveness

Service:

Quick response, On time delivery and Excellent service

Team work:

Complete teamwork, including sales team, Marketing team, engineering team, R&D team, Manufacturing team, logistics team. All is for supporting and servicing a satisfy service for customers.

Easy Release Construction Grey Silicone Pads For LED Power Supply

FAQ

Q: What kind of packaging you offer?

A: During the packaging process, preventive measures will be taken by us to assure that the goods are in a good condition during storage and delivery.

Q:Do big buyers have promotional prices?

A: Yes, if you are a big buyer in a certain area, Ziitek will provide you with promotional prices, which will help you start your business here. Buyers with long-term cooperation will have better prices.
