3.0 Amp 60V SMD Schottky Barrier Diode 30BQ060PBF With DO-214AB
3.0 Amp 60V SMD Schottky Barrier Diode 30BQ060PBF With DO-214AB
3.0 Amp 60V SMD Schottky Barrier Diode 30BQ060PBF With DO-214AB
3.0 Amp 60V SMD Schottky Barrier Diode 30BQ060PBF With DO-214AB
3.0 Amp 60V SMD Schottky Barrier Diode 30BQ060PBF With DO-214AB
3.0 Amp 60V SMD Schottky Barrier Diode 30BQ060PBF With DO-214AB
Specifications
Brand Name :
XUYANG
Model Number :
30BQ060PBF
Certification :
ISO9001/RoHS
Place of Origin :
China
MOQ :
3000PCS
Price :
negotiation
Payment Terms :
T/T, Western Union
Supply Ability :
100000pcs per 1 week
Delivery Time :
15 - 20 work days
Packaging Details :
tape in reel, 3000pcs/reel
Part number :
30BQ060PBF
IF :
3A
Voltage :
60V
Package :
SMC/DO-214AB
Junction Temperature :
-55-150°C
VF at IF :
0.52V
IRM :
20 mA at 125 °C
EAS :
6.0 mJ
Description

3.0 Amp 60V SMD Schottky Rectifier Diode 30BQ060PBF With DO-214AB


FEATURES
• Small foot print, surface mountable
• Very low forward voltage drop
• High frequency operation
• Guard ring for enhanced ruggedness and long term reliability
• Lead (Pb)-free (“PbF” suffix)
• Designed and qualified for industrial level

DESCRIPTION
The 30BQ060PBF surface mount Schottky rectifier has been designed for applications requiring low
forward drop and small foot prints on PC boards. Typical applications are in disk drives, switching
power supplies, converters, freewheeling diodes, battery charging, and reverse battery protection.

MAJOR RATINGS AND CHARACTERISTICS
SYMBOLCHARACTERISTICSVALUESUNITS
IF(AV)Rectangular waveform3.0A
VRRM 60V
IFSMtp = 5 μs sine1200A
VF3.0 Apk, TJ = 125 °C0.52V
TJRange- 55 to 150°C

VOLTAGE RATINGS
PARAMETERSYMBOL30BQ060PBFUNITS
Maximum DC reverse voltageVR60V
Maximum working peak reverse voltageVRWM

ABSOLUTE MAXIMUM RATINGS
PARAMETERSYMBOLTest ConditionVALUESUNITS
Maximum average forward currentIF(AV)50 % duty cycle at TL = 123 °C, rectangular waveform3.0A
50 % duty cycle at TL = 113 °C, rectangular waveform4.0

Maximum peak one cycle
non-repetitive surge current

IFSM5 μs sine or 3 μs rect. pulse

Following any rated
load condition and with
rated VRRM applied

1200
10 ms sine or 6 ms rect. pulse130
Non-repetitive avalanche energyEASTJ = 25 °C, IAS = 1.0 A, L = 12 mH5.0mJ
Repetitive avalanche currentIAR

Current decaying linearly to zero in 1 μs
Frequency limited by TJ maximum VA = 1.5 x VR typical

1.0A

ELECTRICAL SPECIFICATIONS
PARAMETERSYMBOLTest ConditionVALUESUNITS
Maximum forward voltage dropVFM(1)3ATJ = 25 °C0.58V
6A0.76
3ATJ = 125 °C0.52
6A0.66
Maximum reverse leakage currentIRMTJ = 25 °CVR = Rated VR0.5
TJ = 125 °C20mA
Maximum junction capacitanceCTVR = 5 VDC (test signal range 100 kHz to 1 MHz), 25 °C180pF
Typical series inductanceLSMeasured lead to lead 5 mm from package body3.0nH
Maximum voltage rate of changedV/dtRated VR10 000V/μs

Note
(1) Pulse width = 300 μs, duty cycle = 2 %

THERMAL - MECHANICAL SPECIFICATIONS
PARAMETERSYMBOLTest ConditionVALUESUNITS

Maximum junction and storage
temperature range

TJ (1), TStg - 55 to 150°C
Maximum thermal resistance, junction to leadRthJL (2)DC operation12°C/W

Maximum thermal resistance,
junction to ambient

RthJA48


Drawing:
3.0 Amp 60V SMD Schottky Barrier Diode 30BQ060PBF With DO-214AB
3.0 Amp 60V SMD Schottky Barrier Diode 30BQ060PBF With DO-214AB


What can you from XUYANG?
Best service: with 10 years experience in exporting sales staff will service you.
High quality: help you to avoid purchasing risk.
Short delivery: help you to save time.
Competitive price: the price is not the lowest but the highest cost performance
OEM/ODM: we are confident we can meet you OEM/ODm requirements.
