35V VR Band Switching Diode 1SS265 With Standard Glass Case RoHS Approval
35V VR Band Switching Diode 1SS265 With Standard Glass Case RoHS Approval
35V VR Band Switching Diode 1SS265 With Standard Glass Case RoHS Approval
35V VR Band Switching Diode 1SS265 With Standard Glass Case RoHS Approval
35V VR Band Switching Diode 1SS265 With Standard Glass Case RoHS Approval
35V VR Band Switching Diode 1SS265 With Standard Glass Case RoHS Approval
Specifications
Brand Name :
XUYANG
Model Number :
1SS265
Certification :
ISO9001/RoHS
Place of Origin :
China
MOQ :
5000pcs
Price :
negotiation
Payment Terms :
T/T, Western Union
Supply Ability :
100000pcs per 1 week
Delivery Time :
5 - 8 work days
Packaging Details :
tape in box, 5000pcs/box
Name :
High Speed Switching Diode
Part number :
1SS265
VR :
35V
Package :
DO-34
Cathode band :
Black
Shipping by :
DHL\UPS\Fedex\EMS\sea
Description

Band Speed Switching Diode Standard Glass Case 1SS265 DO-34 Package


Features
• Detection efficiency is very good.
• Small temperature coefficient.
• High reliability with glass seal..


Absolute Maximum Ratings
Tj=25℃

Parameter Symbol Value Unit
Reverse voltage VR 35 V
Average certified current Io 100 mA
Junction temperature Tj 150 °C
Storage temperature range Tstg -55~+150 ℃



Electrical Characteristics
Tj=25℃

Parameter Test Condition Symbol Min Typ Max Unit
Forward Current VF = 1V IF 4.5 - mA
Reverse current VR= 6V IR - - 100 μA
Capacitance f =1MHz, VR= 6V C - - 1.5 pF
Frequency resistance f=100MH Z, I F =10mA r f - 0.6 Ω

Note: 1. Failure criterion; IR ≥ 140 μA at VR = 6 V
35V VR Band Switching Diode 1SS265 With Standard Glass Case RoHS Approval

35V VR Band Switching Diode 1SS265 With Standard Glass Case RoHS Approval
What can you from XUYANG?
Best service: with 10 years experience in exporting sales staff will service you.
High quality: help you to avoid purchasing risk.
Short delivery: help you to save time.
Competitive price: the price is not the lowest but the highest cost performance
OEM/ODM: we are confident we can meet you OEM/ODm requirements.
