Electric Brass Hot Runner Spring Coil Heater Heating Element
Electric Brass Hot Runner Spring Coil Heater Heating Element
Electric Brass Hot Runner Spring Coil Heater Heating Element
Electric Brass Hot Runner Spring Coil Heater Heating Element
Electric Brass Hot Runner Spring Coil Heater Heating Element
Electric Brass Hot Runner Spring Coil Heater Heating Element
Specifications
Brand Name :
GME
Certification :
CE
Place of Origin :
China
MOQ :
50pcs
Payment Terms :
T/T, Western Union, MoneyGram, L/C
Supply Ability :
100000 pcs per Month
Delivery Time :
7~10 working days
Packaging Details :
cartons， pallet
Power Source :
Electric
Dimension :
Customized
Voltage :
110-240V / 50-60Hz
Warranty :
one year
power :
195W-690W
Style :
straight or coil
Heating wire material: :
Cr20Ni80
Coiling Scheme :
Tangential, radial exits, axial
Material :
Brass or stainless steel
Color :
Copper
Application :
Widely used
Height :
10mm~200mm
Description

Electric Brass Hot Runner Spring Coil Heater Heating Element

Description:

hot runner coil heater according with different sizes (the sprue bush or nozzle) design and manufacturing, the sleeve is made of high quality stainless steel or copper, inner sleeve, outer there are various winding section (round, square or flat) heating coil, temperature uniformity, thermal inertia characteristics, can be integrated with the K type, J type or E type control temperature thermocouple

Specification:

Minimum diameter Φ

10mm

Voltage

12V- 400V

Wattage tolerance

±10%

Material

SS304/SS321/SS310/SS316 (Customized)

Sleeve material

Brass

Resistance

±10%

Dielectric strength

600V 800V 1000V

Insulation(cold 1000V)

>10 MΩ

Leakage current(cold)

<0.5mA

Max power density

10W/cm²

Heating length tolerance

±0.05mm

Maximum working temperature allowed on sheath

Max.750℃ / 1380°F

Build-in Thermocouple

Type K/ J/ E

Standard supply 1000mm PTEE insulated nickel lead wire

Material of lead wire:Fiberglass, Kevlar, Telfon, Silicone Rubber, Metal braided, SUS armoured.


Application:

1.Injection molding machine nozzle
2. Hot Runner Nozzles & Bushings
3. Packaging machinery
4. Hot runner Injection Molds

5. Injection & Blow Moulding Machine Nozzles
6. PET preform & Thin wall container Moulds
7. Hot runner Manifolds

Electric Brass Hot Runner Spring Coil Heater Heating Element
