500C Heat Resistant Cable Mica Wrapped Fiberglass Braided Wire Pure Nickel Wire
500C Heat Resistant Cable Mica Wrapped Fiberglass Braided Wire Pure Nickel Wire
500C Heat Resistant Cable Mica Wrapped Fiberglass Braided Wire Pure Nickel Wire
500C Heat Resistant Cable Mica Wrapped Fiberglass Braided Wire Pure Nickel Wire
500C Heat Resistant Cable Mica Wrapped Fiberglass Braided Wire Pure Nickel Wire
500C Heat Resistant Cable Mica Wrapped Fiberglass Braided Wire Pure Nickel Wire
Specifications
Brand Name :
GME
Model Number :
type K, Type J
Certification :
CE
Place of Origin :
China
MOQ :
500meters
Price :
USD$0.5-1.5/meter
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
20000meters
Delivery Time :
10 days
Packaging Details :
carton
type :
insulated
conductor material :
copper, copper plate nickle, pure nickle
insulation material :
Silicone, fiberglass PFA, FEP, PTFE, PVC
sheath material :
Fluoroplastic
treatment :
hydrogen annealing
Size :
as customized size
Description

500C heat resistant cable high temperature mica wrapped fiberglass braided wire pure nickel wire

Description:

Among many metal materials, nickel is considered to have better resistance to accelerated oxidation at high temperature. The melting point of nickel is about twice as high as that of copper. fiberglass braided 500 degree high temperature cable Copper conductors coated with nickel have a slightly higher resistivity, but are flexible and resistant to fatigue. At 250℃, the use of nickel-copper conductor is very important, usually 2% of the weight of nickel coating is sufficient. When the temperature is 450℃ or above, should increase the nickel coating thickness. The weight ratio of nickel coating on this type of wire and cable conductor at 450℃ is usually 27%. Pure nickel conductors should be used when the temperature exceeds 600℃, especially when the high and low temperature are constantly alternating.

Products Description:

GN500 Mica Wrapped Fiberglass Braided High Temperature wire
Insulation
Mica Fiberglass
Conductor
Pure copper/Nickel Coated Copper/Pure Nickel
O.D.Tolerance
±0.1mm
Temperature Range
-60℃~500℃
Rated Voltage
450V/750V
Colour
Red/Black/Yellow/Green/Blue/White/
Application
Chemical Industry,Natural gas,etc.High Temperature Environment and Various Electric Appliance.

Application

Applicable to high-temperature environment AC rated voltage 600V or less electrical circuit installation and connection, widely used in electromagnetic heating coil, metallurgy, petroleum, chemical, oil refining, natural gas and other special environments, various mechanical manufacturing fields, various electrical devices requiring fire performance The required wire and cable, as well as various electric heating equipment, electric heating devices and so on.
